Запчасти Doosan Daewoo FUEL FILLER PUMP ASSY OPTION PARTS

-

401-00384

FUEL FILLER PUMP ASS'Y

SC: D

-2шт.

1

401-00373

PUMP;FUEL

desc: POMPE A GAZOLE

1шт.

1A

2181-2755B

ADAPTER

desc: . ADAPTEUR

2шт.

1B

S8180321

SEAL;WASHER

desc: . BAGUE D'ETANCHEITE

2шт.

1C

523-00002A

MOTOR;FUEL TRANSFER PUMP

desc: . MOTEUR

1шт.

1D

407-00001

VANE KIT

desc: . KIT DE VANE

1шт.

1E

2401-1276KT

SEAL KIT

desc: . KIT D'ETANCHEITE

1шт.

2

2185-1353D25

HOSE 3/4-1500L

desc: TUYAU FLEXIBLE

1шт.

3

185-00167D3

HOSE ASS'Y 3/4-4000L

desc: TUYAU FLEXIBLE

1шт.

3B

2420-1258

VALVE;CHECK

desc: . CARTOUCHE DE VANNE

1шт.

3C

2471-1152

STRAINER

desc: . FILTRE

1шт.

3D

2160-1336

CAP;STRAINER

desc: . CHAPEAU

1шт.

4

2181-2104D6

ADAPTER PF1/2

desc: ADAPTEUR

1шт.

5

S8470032

CLAMP;HOSE

desc: ATTACHE

3шт.

6

S8000181

O-RING

desc: JOINT TORIQUE

2шт.

7

2181-2295D15

ELBOW PF1/2-12

desc: COUDE

1шт.

8

S0508553

BOLT M8X1.25X14

desc: BOULON A 6 PANS

4шт.

9

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

4шт.

10

2124-1509D4

CLIP

desc: ATTACHE

1шт.

11

S4012533

NUT M8

desc: ECROU

1шт.
