Запчасти Doosan Daewoo SWING DEVICE ASSY BODY PARTS

-

401-00387

SWING DEVICE ASS'Y

SC: D

-2шт.

1

401-00036H

SWING DEVICE SUB ASS'Y

desc: SYSTEME D'ORIENTATION

1шт.

1A

401-00086A

MOTOR;SWING

desc: . SYSTEME D'ORIENTATION

1шт.

1B

404-00017H

REDUCTION GEAR ASS'Y

desc: . BOITE REDUCTEUR

1шт.

1C

2181-1113D2

REDUCER PT1/2XPT3/8

desc: . REDUCEUR

1шт.

1D

186-00013

COCK

desc: . ROBINET DE PURGE

1шт.

1E

2181-1913D24

REDUCER PT1/2XPT3/4

desc: . REDUCEUR

1шт.

1F

2182-1662

PIPE

desc: . TUYAU

1шт.

1G

2119-1063A

CAP;PIPE

desc: . CHAPEAU

1шт.

1H

S8450012

CLAMP;HOSE

desc: . ATTACHE

1шт.

1I

184-00016

HOSE;VINYL

desc: . TUYAU FLEXIBLE

1шт.

2

S0570166

BOLT M20X2.5X65

desc: BOULON

11шт.

3

2114-9012A

WASHER;HARD

desc: RONDELLE

11шт.

4

2123-4030

PIN;LOCK

desc: GOUPILLE

1шт.

5

160-00027

CAP;RUBBER

desc: CHAPEAU

1шт.
