Запчасти Doosan Daewoo PILOT PIPING-ARTI.BOOM OPTION PARTS-FRONT

-

400-00621

PILOT PIPING

SERIAL: 1034

-2шт.

1

420-00160

VALVE;PEDAL

SERIAL: 1034-1139

1шт.

1

420-00347

VALVE;PEDAL

SERIAL: 1140

1шт.

2

S5110603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

3

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

2шт.

4

2181-1126D85

ADAPTER PFO1/4-PF3/8

desc: RACCORD ADAPTATEUR

1шт.

6

2181-1126D122

ADAPTER PFO1/4-PF3/8

desc: RACCORD ADAPTATEUR

1шт.

7

S8000111

O-RING

desc: JOINT TORIQUE

11шт.

8

2181-1126D14

ADAPTER PFO-PF3/8

desc: RACCORD ADAPTATEUR

6шт.

9

2181-1702D4

ELBOW

desc: COUDE

3шт.

10

2420-9158

VALVE;SHUTTLE

desc: CLAPET BALADEUR

1шт.

11

S0556453

BOLT M8X1.25X55

desc: BOULON A 6 PANS

2шт.

12

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

13

2184-1060D8

HOSE PF3/8-400L

desc: TUYAU FLEXIBLE

1шт.

14

DS2054214

HOSE PF3/8-330L

desc: TUYAU FLEXIBLE

1шт.

15

2184-1045D152

HOSE PF1/4-2000L

desc: TUYAU FLEXIBLE

1шт.

16

2184-1045D251

HOSE PF1/4-2500L

SERIAL: 1034-1139

1шт.

16

2184-1045D148

HOSE PF1/4-1800L

SERIAL: 1140

1шт.

17

2184-1045D104

HOSE PF1/4-2400L

desc: TUYAU FLEXIBLE

1шт.

18

2184-1046D55

HOSE PF1/4-530L

desc: TUYAU FLEXIBLE

1шт.

19

S8000141

O-RING

desc: JOINT TORIQUE

3шт.

20

2181-1950D2

PLUG

desc: BOUCHON

1шт.

21

2181-2281D13

TEE

desc: TE

2шт.

22

2181-1917D55

ADAPTER PF1/4-PF3/8

desc: RACCORD ADAPTATEUR

1шт.

23

2184-1046D32

HOSE PF1/4-480L

desc: TUYAU FLEXIBLE

1шт.

24

2197-1817

BRACKET;PEDAL(L.H)

desc: SUPPORT

1шт.

25

2161-2257

RUBBER;PEDAL

desc: CAOUTCHOUC

1шт.

26

S2211861

BOLT;SOCKET M10X1.5X20

SERIAL: 1034-1139

2шт.

26

S2211866

BOLT;SOCKET M10X1.5X20

SERIAL: 1140

2шт.
