Запчасти Doosan Daewoo MAIN PIPING(1)-PUMP BODY PARTS

-

400-00013A

MAIN PIPING

SERIAL: 1001-1216

-2шт.

1

426-00054

VALVE;CONTROL

desc: VANNE

1шт.

8

2184-1124D193

HOSE(PUMP)-850L

desc: TUYAU FLEXIBLE

1шт.

9

2184-1124D194

HOSE(PUMP)-770L

desc: TUYAU FLEXIBLE

1шт.

19

S0515353

BOLT M12X1.75X35

desc: BOULON A 6 PANS

4шт.

20

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

26

S2212461

BOLT;SOCKET M10X1.5X40

SERIAL: 1001-1066

4шт.

26

S2212466

BOLT;SOCKET M10X1.5X40

SERIAL: 1067

4шт.

28

S2212261

BOLT;SOCKET M10X1.5X30

SERIAL: 1001-1066

16шт.

28

S2212266

BOLT;SOCKET M10X1.5X30

SERIAL: 1067

16шт.

29

2180-1026D19

O-RING

desc: JOINT TORIQUE

3шт.

30

2181-9078

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

4шт.

33

2180-1026D2

O-RING

desc: JOINT TORIQUE

5шт.

35

2181-9080

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

8шт.

38

2181-2620

BLOCK;SPACER

desc: BLOC

1шт.

55

S2212861

BOLT;SOCKET M10X1.5X60

SERIAL: 1001-1066

4шт.

55

S2212866

BOLT;SOCKET M10X1.5X60

SERIAL: 1067

4шт.

56

2547-9045

SENSOR;PRESSURE

desc: CAPTEUR

2шт.

57

184-00007

HOSE-1100L

desc: TUYAU FLEXIBLE

1шт.

58

423-00040A

BLOCK

desc: BLOC

1шт.
