Запчасти Doosan Daewoo COMMON PIPING POWER TRAIN

-

2400-1478

COMMON PIPING

desc: CONDUITES

-2шт.

1

S8000181

O-RING P18

REP_PNO: 8202-014

4шт.

2

2181-1126D6

ADAPTER;S PF.PFO1/2

desc: RACCORD ADAPTATEUR

2шт.

3

2183-3799

PIPE

SERIAL: 1-111

1шт.

3

2183-3799A

PIPE

SERIAL: 112

1шт.

4

2184-1036D287

HOSE PF1/2-1050L

desc: TUYAU FLEXIBLE

1шт.

5

2184-1036D235

HOSE PF1/2-900L

desc: TUYAU FLEXIBLE

1шт.

6

2184-1096D72

HOSE PF1/2-2600L

desc: TUYAU FLEXIBLE

1шт.

7

S8000241

O-RING P24

desc: JOINT TORIQUE P24

2шт.

8

2181-1126D24

ADAPTER PFO3/4-PF1/2

desc: RACCORD ADAPTATEUR

2шт.

9

2124-1026D1

CLAMP;PIPE

desc: ATTACHE DE TUBE

1шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

11

S0558453

BOLT M10X1.5X45

desc: BOULON A 6 PANS

1шт.

12

2158-1003D4

PROTECTOR;HOSE

SERIAL: 1-2

1шт.

12

2158-1003D4

PROTECTOR;HOSE

SERIAL: 3

2шт.

13

2124-1084D3

CLIP;BAND

desc: ATTACHE

2шт.

14

2181-1126D83

ADAPTER PFO.PF1/2

desc: RACCORD ADAPTATEUR

2шт.
