Запчасти Doosan Daewoo COMMON PIPING(OPT.)-E.D OPTION PARTS

-

2400-1906

COMMON PIPING

desc: CONDUITES

1шт.

1

S8000181

O-RING P18

desc: JOINT TORIQUE

5шт.

2

2181-1126D6

ADAPTER;S PF.PFO1/2

desc: RACCORD ADAPTATEUR

2шт.

3

2183-3799A

PIPE

desc: CONDUITE

1шт.

4

2184-1036D287

HOSE PF1/2-1050L

desc: TUYAU FLEXIBLE

1шт.

5

2184-1036D235

HOSE PF1/2-900L

desc: TUYAU FLEXIBLE

1шт.

6

2184-1096D72

HOSE PF1/2-2600L

desc: TUYAU FLEXIBLE

1шт.

7

S8000241

O-RING P24

desc: JOINT TORIQUE

3шт.

8

2181-1126D24

ADAPTER PFO3/4-PF1/2

desc: RACCORD ADAPTATEUR

2шт.

9

2124-1026D1

CLAMP;PIPE

desc: ATTACHE DE TUBE

1шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

11

S0558453

BOLT M10X1.5X45

desc: BOULON A 6 PANS

1шт.

12

2158-1003D4

PROTECTOR;HOSE

desc: PROTECTEUR

2шт.

13

2124-1084D3

CLIP;BAND

desc: ATTACHE

2шт.

14

2181-1126D83

ADAPTER PFO.PF1/2

desc: RACCORD ADAPTATEUR

2шт.

15

S8000181

O-RING P18

desc: JOINT TORIQUE

3шт.

16

2181-1126D14

ADAPTER PFO. PF1/4

desc: RACCORD ADAPTATEUR

2шт.

17

2184-1061D2

HOSE PF1/4-1235L

desc: TUYAU FLEXIBLE

1шт.

18

2181-1702D3

ELBOW PFO1/4-PF3/8

desc: COUDE

1шт.

19

2184-1036D181

HOSE PF3/8-1200L

desc: TUYAU FLEXIBLE

1шт.

20

2420-9291A

VALVE;SELECTOR

desc: VANNE DE SELECTION

1шт.

21

S5010613

WASHER;PLAIN M10

desc: RONDELLE

3шт.

22

S2213161

BOLT;SOCKET M10X1.5X75

desc: BOULON A 6 PANS CREUX

3шт.

23

2181-1950D7

PLUG PFO1/2

desc: BOUCHON

1шт.

24

2181-1950D5

PLUG PFO3/4

desc: BOUCHON

1шт.
