Запчасти Doosan Daewoo ROTARY GROUP-L.H HYDRAULIC PARTS

-

4100221347

GROUP;ROTARY

desc: GROUPE ROTATOIRE

1шт.

1

1100146276

SHAFT

desc: ARBRE

1шт.

2

1100218931

BLOCK;CYLINDER

desc: BLOC-CYLINDRES

1шт.

3

1100037439

PIN

desc: GOUJON

1шт.

4

1100218922

PISTON

desc: PISTON

7шт.

5

1100037411

PISTON RING

desc: PISTON

7шт.

6

1100029117

PLATE;CONTROL

desc: PLAQUE

1шт.

7

1100038569

HOLDER;SPRING

desc: ENSEMBLE SUPPORT

1шт.

8

1100038579

SPRING

desc: RESSORT

4шт.

9

1700625744

PLATE

desc: PLAQUE

1шт.

10

1701536177

BOLT;SOCKET M5X16 DIN7985-8.8

desc: BOULON A 6 PANS CREUX

14шт.

11

1100081591

BEARING

desc: PALIER

1шт.

12

1701511022

BEARING 4T-30211

desc: PALIER

1шт.

13

1100081582

PIECE;DISTANCE

desc: CONNECTEUR

1шт.

14

1100148704

NUT

desc: ECROU

1шт.

16

1163260007

SEAL

desc: JOINT

1шт.

17

1100018364

SEAL ISPID50727F

desc: JOINT

1шт.

18

1302173009

O-RING 110 JIS B2804

desc: JOINT TORIQUE

1шт.

19

1300465003

O-RING 243 1115-70 104.37X3.53 AS 568A

desc: JOINT TORIQUE

1шт.

20

1100038258

SHIM 14X25X0.5

desc: CALE

1шт.

21

1100038267

SHIM 14X25X0.3

desc: CALE

1шт.

22

1100038276

SHIM 14X25X0.1

desc: CALE

1шт.

23

1303037463

SHIM 14X25X0.15

desc: CALE

1шт.

30

1700859488

SHIM 100X120X0.5

desc: CALE

1шт.

31

1700845948

SHIM 100X120X0.3

desc: CALE

1шт.

32

1700845911

SHIM 100X120X0.1

desc: CALE

1шт.

33

1100098929

SHIM 100X120X0.15

desc: CALE

1шт.
