Запчасти Doosan Daewoo CRANK SHAFT ENGINE PARTS

-

65.02101-7024

CRANK SHAFT ASS'Y

desc: ENSEMBLE VILEBREQUIN

1шт.

1

65.02101-0024

SHAFT;CRANK

desc: . ARBRE

1шт.

2

65.90430-0014

BOLT;CRANK SHAFT

SERIAL: 500082

12шт.

2

65.90430-0014A

BOLT;CRANK SHAFT

SERIAL: 500083

12шт.

3

65.02110-0011

WEIGHT;BALANCE

desc: . MASSE D'EQUILIBRAGE

6шт.

4

65.02115-0007

GEAR;CRANK SHAFT

desc: PIGNON DE VILEBREQUIN

1шт.

5

06.22022-0912

PIN;DOWEL 6mX20

desc: GOUJON

1шт.

11

65.01110-6351

METAL;MAIN STD

desc: COUSSINET COTE STD

7шт.

11

65.01110-6352

METAL;MAIN 0.25

desc: COUSSINET 0.25

7шт.

11

65.01110-6353

METAL;MAIN 0.50

desc: COUSSINET 0.50

7шт.

11

65.01110-6354

METAL;MAIN 0.75

desc: COUSSINET 0.75

7шт.

11

65.01110-6355

METAL;MAIN 1.00

desc: COUSSINET 1.00

7шт.

12

65.01150-0015

WASHER;THRUST(UPPER) STD

desc: RONDELLE DE BUTEE(HAUT) STD

2шт.

12

65.01150-0019

WASHER;THRUST(UPPER) 0.25

desc: RONDELLE DE BUTEE(HAUT) 0.25

2шт.

12

65.01150-0020

WASHER;THRUST(UPPER) 0.50

desc: RONDELLE DE BUTEE(HAUT) 0.50

2шт.

12

65.01150-0021

WASHER;THRUST(UPPER) 0.75

desc: RONDELLE DE BUTEE(HAUT) 0.75

2шт.

12

65.01150-0022

WASHER;THRUST(UPPER) 1.00

desc: RONDELLE DE BUTEE(HAUT) 1.00

2шт.

13

65.01150-0016

WASHER;THRUST(LOWER) STD

desc: RONDELLE DE BUTEE(BAS) STD

2шт.

13

65.01150-0023

WASHER;THRUST(LOWER) 0.25

desc: RONDELLE DE BUTEE(BAS) 0.25

2шт.

13

65.01150-0024

WASHER;THRUST(LOWER) 0.50

desc: RONDELLE DE BUTEE(BAS) 0.50

2шт.

13

65.01150-0025

WASHER;THRUST(LOWER) 0.75

desc: RONDELLE DE BUTEE(BAS) 0.75

2шт.

13

65.01150-0026

WASHER;THRUST(LOWER) 1.00

desc: RONDELLE DE BUTEE(BAS) 1.00

2шт.

14

65.02201-7028

DAMPER;VIBRATION

desc: AMORTISSEUR DE VIBRATIONS

1шт.

15

06.16044-0210

WASHER;SPRING B8

desc: RONDELLE ELASTIQUE B8

8шт.

16

06.01283-7113

BOLT;HEX. M8X1.25X20

desc: BOULON A 6 PANS

8шт.

17

65.02601-0133

PULLEY;V-BELT

desc: POULIE DE COURROIE TRAPEZOIDALE

1шт.

18

65.90720-0022

WASHER

desc: RONDELLE

1шт.

19

06.02106-0620

BOLT;SOCKET HEAD

desc: BOULON A 6 PANS CREUX

8шт.

20

65.02301-5028

FLY WHEEL ASS'Y

SERIAL: 400015

1шт.

20

65.02301-5062

FLY WHEEL ASS'Y

SERIAL: 400016

1шт.

20-1

65.02301-0160

WHEEL;FLY

desc: VOLANT

1шт.

20-1

65.02301-0215

WHEEL;FLY

desc: VOLANT

1шт.

21

65.02301-0010

GEAR;STARTER RING

desc: COURONNE DENTEE DEMARREUR

1шт.

22

06.22220-1208

PIN;SPIRAL LOCK 8X16

desc: GOUPILLE DE BLOCAGE

1шт.

23

06.16731-2110

WASHER;SPRING A14

desc: RONDELLE ELASTIQUE A14

6шт.

24

65.90001-0084

BOLT;HEX. M14X1.5X40

desc: BOULON A 6 PANS

6шт.

25

65.01505-0030

COVER;DUST

desc: PARE-POUSSIERES

1шт.
