Запчасти Doosan Daewoo CAM SHAFT ENGINE PARTS

1

65.04401-0014

SHAFT;CAM

desc: ARBRE A CAMES

1шт.

2

65.90720-0099

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

3

65.98112-0038

FLANGE

desc: BRIDE

1шт.

4

06.16731-2105

WASHER;SPRING A6

SERIAL: 400025

2шт.

4

06.16731-2105

WASHER;SPRING A6

SERIAL: 400026

5

06.01283-6910

BOLT;HEX. M6X12

SERIAL: 400025

2шт.

5

65.90001-6003

BOLT;HEX. M6X14

SERIAL: 400026

2шт.

6

65.04501-0057

GEAR;CAM SHAFT

desc: PIGNON D'ARBRE A CAMES

1шт.

7

06.22022-1016

PIN;DOWEL 8m6X36

desc: GOUJON

1шт.

8

06.16731-2107

WASHER;SPRING A8

SERIAL: 400025

4шт.

8

06.16731-2107

WASHER;SPRING A8

SERIAL: 400026

9

06.01013-9114

BOLT;HEX. M8X45

SERIAL: 400025

4шт.

9

06.01913-3120

BOLT;HEX. M8X1.25X45

SERIAL: 400026

4шт.

11

65.01506-0008

PIN;IDLE GEAR

desc: GOUJON DE PIGNON FOU

1шт.

12

65.04505-5008

IDLE GEAR ASS'Y

desc: BARBOTIN

1шт.

13

65.04507-0003

BEARING;IDLE GEAR

desc: . PALIER

1шт.

14

65.04505-0005

GEAR;CAM SHAFT IDLE

desc: . PIGNON

1шт.

15

65.90720-0019

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

16

06.16731-2107

WASHER;SPRING A8

SERIAL: 400025

2шт.

16

06.16731-2107

WASHER;SPRING A8

SERIAL: 400026

17

06.01014-9120

BOLT;HEX. M8X75

SERIAL: 400025

2шт.

17

06.01914-3126

BOLT;HEX. M8X75

SERIAL: 400026

2шт.

18

65.04101-0041

VALVE;INTAKE

desc: SOUPAPE D'ADMISSION

6шт.

19

65.44101-0042

VALVE;EXHAUST

desc: VANNE

6шт.

20

65.04902-0006

SEAL VALVE STEM

SERIAL: 400009

12шт.

20

65.04902-0009

SEAL VALVE STEM

SERIAL: 400010

12шт.

21

65.04103-0009

SEAT;VALVE SPRING

desc: SIEGE DE RESSORT DE SOUPAPE

12шт.

22

65.04102-0007

SPRING;VALVE(INTAKE)

desc: RESSORT DE SOUPAPE(ADMISSION)

6шт.

23

65.04102-6002

SPRING;VALVE(EXHAUST)

desc: RESSORT

6шт.

24

65.04102-0004

SPRING;VALVE(EXHAUST INNER)

desc: . RESSORT

6шт.

25

65.04102-0003

SPRING;VALVE(EXHAUST OUTER)

desc: . RESSORT

6шт.

26

65.04103-0013

RETAINER;VALVE SPRING

desc: COUPELLE DE RESSORT DE SOUPAPE

12шт.

27

65.04104-0006

COTTER;VALVE

desc: CLAVETTE DE SOUPAPE

24шт.

28

65.04200-6016

ROCKER ARM & SHAFT ASS'Y(WITH 29-42)

SERIAL: 409999

3шт.

28

65.04200-6025

ROCKER ARM & SHAFT ASS'Y(WITH 29-42)

SERIAL: 500001

3шт.

29

65.97601-0055

SPRING;ROCKER ARM SHAFT

desc: RESSORT D'AXE DE CULBUTEURS

3шт.

30

65.04201-5013

ROCKER ARM ASS'Y

desc: ENSEMBLE AXE DE CULBUTEURS

12шт.

30

65.04201-0006

ARM;ROCKER

desc: . AXE DE CULBUTEURS

12шт.

30

65.93020-0032

BUSH

desc: . DOUILLE

12шт.

31

65.04205-0003

BOLT;ADJUSTING M10X10

desc: BOULON A 6 PANS

12шт.

32

65.90501-0003

NUT;HEX. M10X1.0

desc: ECROU

12шт.

33

65.04202-0007

BRACKET;ROCKER ARM SHAFT

desc: SUPPORT D'AXE DE CULBUTEURS

6шт.

33

65.04202-0012

BRACKET;ROCKER ARM SHAFT

desc: SUPPORT D'AXE DE CULBUTEURS

3шт.

33

65.04202-0013

BRACKET;ROCKET ARM SHAFT

desc: SUPPORT

3шт.

34

06.01493-4315

BOLT;HEX. M12X1.5X80

desc: BOULON A 6 PANS

6шт.

34

65.90020-0056

BOLT;HEX. M12X1.5X80

desc: BOULON A 6 PANS

6шт.

35

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE A12

6шт.

35

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE A12

36

06.01013-9221

BOLT;HEX. M10X80

desc: BOULON A 6 PANS

6шт.

37

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE A10

6шт.

37-1

06.15030-0514

WASHER 10.5

desc: RONDELLE

6шт.

38

65.90710-0039

WASHER;ROCKER ARM

desc: RONDELLE D'AXE DE CULBUTEURS

12шт.

39

06.29010-0120

RING;SNAP 24X1.2

desc: BAGUE

6шт.

40

65.04203-5009

ROCKER ARM SHAFT ASS'Y

desc: ENSEMBLE AXE DE CULBUTEUR

3шт.

41

65.04203-0009

SHAFT;ROCKER ARM

desc: . ARBRE

3шт.

42

65.90302-0012

PLUG

SC: D

6шт.

43

65.04301-0005

TAPPET;VALVE

desc: POUSSOIR DE TIGE DE VANNE

12шт.

44

65.04302-5010

PUSH ROD ASS'Y

desc: ENSEMBLE TIGE DE CULBUTEUR

12шт.
