Запчасти Doosan Daewoo PISTON ENGINE PARTS

1

65.02501-0074

PISTON

desc: PISTON

6шт.

2

65.02503-0054

RING;TOP 111X3.5

desc: BAGUE

6шт.

3

65.02503-0091

RING;SECOND 111X3.5

desc: BAGUE

6шт.

4

65.02503-0101

RING;OIL 111X4

SERIAL: 500081

6шт.

4

65.02503-0115

RING;OIL 111X4

SERIAL: 500082

6шт.

5

65.02502-0010

PIN;PISTON 42X20X95

desc: GOUJON

6шт.

6

06.29020-0126

RING;SNAP 42X1.75

desc: BAGUE

12шт.

7

65.02401-6101

CONNECTING ROD ASS'Y

SERIAL: 500082

6шт.

7

65.02401-6101C

CONNECTING ROD ASS'Y

SERIAL: 500083

6шт.

8

65.02401-0030

ROD;CONNECTING

desc: . BIELLE;ENSEMBLE DE BIELLE

6шт.

9

65.90020-0009

BOLT;CONNECTING ROD

SERIAL: 500082

12шт.

9

65.90020-0009C

BOLT;CONNECTING ROD

SERIAL: 500083

12шт.

10

65.91301-0010

PIN;DOWEL

desc: . GOUJON D'ASSEMBLAGE

12шт.

11

65.02405-0014

BUSH;SMALL END

SERIAL: 500082

6шт.

11

65.02405-0015B

BUSH;SMALL END

SERIAL: 500083

6шт.

12

65.02410-6073

METAL;CONNECTING ROD STD

SERIAL: 500082

6шт.

12

65.02410-0010

METAL;CONNECTING ROD STD

SERIAL: 500083

6шт.

12

65.02410-6074

METAL;CONNECTING ROD 0.25

SERIAL: 500082

6шт.

12

65.02410-0011

METAL;CONNECTING ROD 0.25

SERIAL: 500083

6шт.

12

65.02410-6075

METAL;CONNECTING ROD 0.5

SERIAL: 500082

6шт.

12

65.02410-0012

METAL;CONNECTING ROD 0.5

SERIAL: 500083

6шт.

12

65.02410-6076

METAL;CONNECTING ROD 0.75

SERIAL: 500082

6шт.

12

65.02410-0013

METAL;CONNECTING ROD 0.75

SERIAL: 500083

6шт.

12

65.02410-6077

METAL;CONNECTING ROD 1.00

SERIAL: 500082

6шт.

12

65.02410-0014

METAL;CONNECTING ROD 1.00

SERIAL: 500083

6шт.
