Запчасти Doosan Daewoo BRAKE PIPING(4) BODY PARTS

-

2400-1599

BRAKE PIPING

SERIAL: 11

1шт.

2

2181-1126D23

ADAPTER PFO1/2.PF3/8

desc: RACCORD ADAPTATEUR

2шт.

10

S8000141

O-RING P14

REP_PNO: 8202-011

2шт.

16

2121-1284

NUT PF3/8

desc: ECROU

2шт.

17

2460-9402

ACCUMULATOR 0.7§¤

SERIAL: 11-361

2шт.

17

2460-9034

ACCUMULATOR 0.75§¤.300bar

SERIAL: 362

2шт.

19

2181-1126D109

ADAPTER M18X1.5. PF1/2

desc: RACCORD ADAPTATEUR

2шт.

20

S8000181

O-RING P18

REP_PNO: 8202-014

2шт.

21

2195-4832

BRACKET

SERIAL: 11-30

1шт.

21

2195-4832A

BRACKET

SERIAL: 31

1шт.

22

S0511753

BOLT M10X1.5X18

desc: BOULON A 6 PANS

4шт.

23

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

7шт.

25

S8000111

O-RING P11

REP_PNO: 8202-009

1шт.

26

2181-2180

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

27

S8180211

SEAL;RING

desc: BAGUE D'ETANCHEITE

1шт.

28

2549-9093

SWITCH;LOW PRESSURE

desc: CONTACT BASSE PRESSION

1шт.

29

2420-9325

VALVE;BRAKE SUPPLY

SERIAL: 11-341

1шт.

29

2420-9325A

VALVE;BRAKE SUPPLY

SERIAL: 342

1шт.

30

S2213561

BOLT;SOCKET M10X1.5X95

desc: BOULON A 6 PANS CREUX

3шт.

41

2184-1026D324

HOSE PF3/8-900L

desc: TUYAU FLEXIBLE

2шт.
