Запчасти Doosan Daewoo BRAKE PIPING(3) BODY PARTS

-

2400-1599

BRAKE PIPING

SERIAL: 1-10

1шт.

10

S8000141

O-RING P14

REP_PNO: 8202-011

4шт.

15

2181-1126D7

ADAPTER;S PF.PFO3/8

desc: RACCORD ADAPTATEUR

4шт.

16

2181-1284

ADAPTER PFO. PF3/8

desc: RACCORD ADAPTATEUR

2шт.

17

2460-9009

ACCUMULATOR 1.4L

desc: RESERVOIR

2шт.

18

S8180291

PACKING

desc: RONDELLE D'ETANCHEITE

2шт.

19

2181-1126D109

ADAPTER M18X1.5. PF1/2

desc: RACCORD ADAPTATEUR

2шт.

20

S8000181

O-RING P18

REP_PNO: 8202-014

2шт.

21

2195-4700

BRACKET

desc: SUPPORT

1шт.

22

S0511753

BOLT M10X1.5X18

desc: BOULON A 6 PANS

4шт.

23

S5102603

WASHER'SPRING M10

desc: RONDELLE ELASTIQUE

7шт.

25

S8000111

O-RING P11

REP_PNO: 8202-009

1шт.

26

2181-2180

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

27

S8180211

SEAL;RING

desc: BAGUE D'ETANCHEITE

1шт.

28

2549-9093

SWITCH;LOW PRESSURE

desc: CONTACT BASSE PRESSION

1шт.

29

2420-9458

VALVE;BRAKE SUPPLY

desc: ENSEMBLE DE FREIN

1шт.

30

S2213561

BOLT;SOCKET M10X1.5X95

desc: BOULON A 6 PANS CREUX

3шт.

40

2184-1036D158

HOSE PF3/8-1030L

desc: TUYAU FLEXIBLE

1шт.

41

2184-1061D178

HOSE PF3/8-1200L

desc: TUYAU FLEXIBLE

1шт.
