Запчасти Doosan Daewoo BRAKE PIPING(1) BODY PARTS

-

2400-1599

BRAKE PIPING

desc: CONDUITES DE FREINS

1шт.

5

2471-9027

FILTER ASS'Y

SERIAL: 1-451

1шт.

5

2471-9054

FILTER ASS'Y

SERIAL: 452

1шт.

6

S0553753

BOLT M6X1.0X55

SERIAL: 1-451

2шт.

6

S0504553

BOLT M6X1.0X14

SERIAL: 452

6шт.

7

S5102303

WASHER;SPRING M6

SERIAL: 1-451

2шт.

7

S5102303

WASHER;SPRING M6

SERIAL: 452

6шт.

10

S8000141

O-RING P14

REP_PNO: 8202-011

3шт.

20

S8000181

O-RING P18

REP_PNO: 8202-014

5шт.

24

2181-1702D2

ELBOW PFO.PF1/2

desc: COUDE

2шт.

31

2181-1951D16

TEE PF3/8.PFO3/8

desc: TE

1шт.

32

2181-1126D6

ADAPTER;S PF.PFO1/2

desc: RACCORD ADAPTATEUR

2шт.

33

2181-9089

FLANGE;SPLIT 1/2"-5000PSI

desc: BRIDE

2шт.

34

2180-1026D30

O-RING SAE1/2

desc: JOINT TORIQUE

1шт.

35

S2209061

BOLT;SOCKET M8X1.25X25

REP_PNO: 8072-084

4шт.

36

2184-1095D10

HOSE PF1/2-550L

desc: TUYAU FLEXIBLE

1шт.

37

2184-1026D330

HOSE PF3/8-2800L

desc: TUYAU FLEXIBLE

1шт.

38

2184-1036D240

HOSE PF1/2-3700L

desc: TUYAU FLEXIBLE

1шт.

39

2184-1036D23

HOSE PF3/8-2800L

desc: TUYAU FLEXIBLE

1шт.

43

2184-1096D67

HOSE PF1/2-3700L

desc: TUYAU FLEXIBLE

1шт.

44

S5110503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

46

2181-1126D27

ADAPTER;LONG PFO.PF3/8

desc: RACCORD ADAPTATEUR

2шт.

48

2197-2201

PLATE

SERIAL: 452

1шт.
