Запчасти Doosan Daewoo LUBRICATION PIPING FRONT PARTS
11
11
11
8
9
10
8
9
10
5
6
7
8
9
10
3
2
4
13
14
16
15
1
2
3
4
12
1
1
12
1
-
400-00159A
FRONT LUBRICATOR
SC: D
-2шт.
1
S6710101
NIPPLE;GREASE
SERIAL: 1001-1012
2шт.
1
2181-1925
ELBOW
SERIAL: 1013
2шт.
2
S6710041
NIPPLE;GREASE
SERIAL: 1001-1012
3шт.
2
S6710041
NIPPLE;GREASE
SERIAL: 1013
5шт.
3
181-00103
REDUCER PT1/8-PF1/4
desc: REDUCEUR
3шт.
4
121-00006
NUT PF1/4
desc: ECROU
3шт.
5
2184-1045D131
HOSE PF1/4-2700L
desc: TUYAU FLEXIBLE
1шт.
6
2184-1045D194
HOSE PF1/4-2800L
desc: TUYAU FLEXIBLE
1шт.
7
2184-1045D127
HOSE PF1/4-2600L
desc: TUYAU FLEXIBLE
1шт.
8
S0511553
BOLT M10X1.5X14
desc: BOULON A 6 PANS
6шт.
9
S5102603
WASHER;SPRING M10
desc: RONDELLE ELASTIQUE
6шт.
10
124-00014
CLAMP;PIPE
desc: FIXATION DE TUYAU
3шт.
11
2181-1110D30
ADAPTER PF1/4-PT1/8
desc: RACCORD ADAPTATEUR
3шт.
12
2181-1117D1
PLUG PT1/8
SERIAL: 1001-1012
1шт.
12
S3524403
PLUG;DRAIN M10X1.5X15
SERIAL: 1013
1шт.
13
181-00525
REDUCER PT1/8-PF1/4
SERIAL: 1013
2шт.
14
S4032833
NUT M14X1.5
SERIAL: 1013
2шт.
15
140-00657
PIPE
SERIAL: 1013
1шт.
16
140-00658
PIPE
SERIAL: 1013
1шт.
