Запчасти Doosan Daewoo CENTER JOINT TRACK PARTS

-

604-00035A

TRACK ASS'Y

SERIAL: 1-50140

-2шт.

-

9604-1033A

TRACK ASS'Y

SERIAL: 50141

-2шт.

10

2480-6043

CENTER JOINT

desc: JOINT TOURNANT

1шт.

10-1

2480-6002

BODY

desc: . CARROSSERIE

1шт.

10-2

2481-6007

SPINDLE

desc: . TOUPIE

1шт.

10-3

2482-6002

COVER

desc: . CAPOT

1шт.

10-4

SJD-100-40

SPACER

desc: . PLAQUE D'ANCRAGE

1шт.

10-5

SJD-100-50

SHIM

desc: . PLAQUE

1шт.

10-6

SJD-100-60

SHIM

desc: . BILLE

1шт.

10-7

SJD-100-70

SEAL;SLIPPER

SC: K

6шт.

10-8

SJD-100-80

O-RING 1AP-120

SC: K

1шт.

10-9

SJD-100-90

O-RING 1BP-100

SC: K

1шт.

10-10

SJD-100-100

O-RING 1BG-120

SC: K

1шт.

10-11

SJD-100-110

PLUG PT3/4

desc: . BOULON A 6 PANS

4шт.

10-12

SJD-100-120

RING;RETAINING

desc: . BOUCHON

1шт.

10-13

SJD-100-130

BOLT M12X1.75X30

desc: . BOUCHON

4шт.

10-14

SJD-100-140

WASHER;SPRING M12

desc: . RONDELLE PLATE GROWER

4шт.

17

S5102703

WASHER;SPRING M12

desc: RONDELLE GROWER M12

4шт.

25

S0515353

BOLT M12X1.75X35

desc: BOULON A 6 PANS

4шт.

*

2480-6043KT

SEAL KIT;CENTER JOINT

desc: KIT D'ETANCHEITE

1шт.
