Запчасти Doosan Daewoo TRACK ASSY-NARROW OPTION PARTS

-

604-00047A

TRACK ASS'Y-NARROW 2.5M

SERIAL: 1-50140

-2шт.

-

9604-1032A

TRACK ASS'Y-NARROW 2.5M

SERIAL: 50141

-2шт.

1

604-00046A

FRAME;TRACK

desc: TRAIN DE ROULEMENT

1шт.

2

109-00028B

BEARING;SWING

SERIAL: 1-50140

1шт.

2

9109-6006

BEARING;SWING

SERIAL: 50141

1шт.

3

401-00034

MOTOR;TRAVEL

desc: MOTEUR D'AVANCE

2шт.

4

2108-1019C

SPROCKET

desc: COURONNE DENTEE

2шт.

5

274-00006

TRACK SPRING ASS'Y

desc: TENDEUR DE CHENILLE

2шт.

6

270-00016

IDLER ASS'Y

desc: BARBOTIN

2шт.

7

2270-9403A

ROLLER;LOWER

desc: ENSEMBLE GALET INFERIEUR

16шт.

8

2273-9011D1

TRACK SHOE ASS'Y(510G)

desc: ENSEMBLE CHENILLES

2шт.

9

2270-1062

ROLLER;UPPER

desc: ENSEMBLE GALET SUPERIEUR

4шт.

10

2480-6043

JOINT;CENTER

desc: JOINT TOURNANT

1шт.

11

2623-4002B

GUARD;LINK

desc: BARRE DE PROTECTION

2шт.

12

2621-1428

COVER

desc: CAPOT

1шт.

13

2403-1002

COVER

desc: CAPOT

1шт.

14

2180-1017A

PACKING

desc: RONDELLE ETANCHE

1шт.

15

621-00236

COVER

desc: CAPOT

2шт.

16

2114-1816

WASHER;HARDEN

desc: RONDELLE

60шт.

17

S5102703

WASHER;SPRING M12

desc: RONDELLE GROWER M12

20шт.

18

S5102901

WASHER;SPRING M16

desc: RONDELLE GROWER M16

8шт.

21

2114-9012

WASHER;HARDEN

SERIAL: 1-50280

36шт.

21

2114-9012A

WASHER;HARDEN

SERIAL: 50281

36шт.

22

2120-2196D1

BOLT;SET M10X1.5X20

desc: BOULON A 6 PANS

2шт.

23

2120-2196D2

BOLT;SET M10X1.5X25

desc: BOULON A 6 PANS

12шт.

24

2420-1242A

VALVE;GREASE

desc: VANNE

2шт.

25

S0515353

BOLT M12X1.75X35

desc: BOULON A 6 PANS

20шт.

26

120-00050

BOLT;FLANGE M16X2.0X45

SERIAL: 1-50280

42шт.

26

120-00050A

BOLT;FLANGE M16X2.0X45

SERIAL: 50281

42шт.

27

S0565561

BOLT M16X2.0X65

desc: BOULON A 6 PANS

60шт.

28

S0721461

BOLT M16X1.5X40

desc: BOULON A 6 PANS

8шт.

29

S0766061

BOLT M16X1.5X90

desc: BOULON A 6 PANS

64шт.

30

S0770261

BOLT M20X1.5X70

desc: BOULON A 6 PANS

36шт.
