Запчасти Doosan Daewoo MAIN PIPING(5)-TRAVEL BODY PARTS

-

9400-1076

MAIN PIPING

SC: D

-2шт.

4

2184-1201D35

HOSE PF3/4-1400L

desc: FLEXIBLE

1шт.

5

2184-1202D88

HOSE PF3/4-1650L

desc: FLEXIBLE

1шт.

6

2184-1202D5

HOSE PF3/4-1300L

desc: FLEXIBLE

1шт.

7

2184-1201D2

HOSE PF3/4-1050L

desc: FLEXIBLE

1шт.

23

2180-1026D2

O-RING

desc: JOINT TORIQUE

4шт.

24

S5110603

WASHER;SPRING M10

desc: RONDELLE GROWER

16шт.

25

2181-9079

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

8шт.

26

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

16шт.

29

S8030121

O-RING

desc: JOINT TORIQUE

4шт.

38

S8000231

O-RING

desc: JOINT TORIQUE

4шт.

39

2181-2627D1

ADAPTER PF3/4-UNF3/4

desc: RACCORD ADAPTATEUR

3шт.

42

2181-2627D11

ADAPTER PF3/4-UNF3/4

desc: RACCORD

1шт.
