Запчасти Doosan Daewoo MAIN PIPING(1)-PUMP BODY PARTS

-

9400-1076

MAIN PIPING

SC: D

-2шт.

1

426-00060

VALVE;CONTROL

SERIAL: 1-50160

1шт.

1

426-E0060A

VALVE;CONTROL

SERIAL: 50161-50233

1шт.

1

426-E0060B

VALVE;CONTROL

SERIAL: 50234

1шт.

12

2184-1100D222

HOSE PF2 3/4-1050L

desc: FLEXIBLE

1шт.

13

2184-1202D89

HOSE PF3/4-830L

desc: FLEXIBLE

1шт.

14

2184-1202D81

HOSE PF3/4-920L

desc: FLEXIBLE

1шт.

18

S0515353

BOLT M12X1.75X35

desc: BOULON A 6 PANS

4шт.

19

S5102703

WASHER;SPRING M12

desc: RONDELLE GROWER M12

4шт.

23

2180-1026D2

O-RING

desc: JOINT TORIQUE

5шт.

29

S8030121

O-RING

desc: JOINT TORIQUE

2шт.

32

423-00040A

BLOCK

desc: BLOC

1шт.

34

2547-9045

SENSOR;PRESSURE

desc: CAPTEUR

2шт.

35

2181-9080

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

8шт.

36

S2212866

BOLT;SOCKET M10X1.5X60

desc: BOULON A 6 PANS CREUX

4шт.

37

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

12шт.

38

S8000231

O-RING

desc: JOINT TORIQUE

2шт.

48

2181-2627D3

ADAPTER

desc: RACCORD

1шт.

49

2181-2627D18

ADAPTER

desc: RACCORD

1шт.
