Запчасти Doosan Daewoo ENGINE MOUNTING BODY PARTS

-

201-00013A

ENGINE ASS'Y

SC: D

-2шт.

1

201-00014

ENGINE-DB58T

desc: MOTEUR

1шт.

11

S5102603

WASHER;SPRING M10

desc: RONDELLE GROWER M10

8шт.

29

2197-1399A

BRACKET

desc: SUPPORT

1шт.

30

2197-1400A

BRACKET

desc: SUPPORT

1шт.

31

S0786253

BOLT M12X1.5X30

desc: BOULON A 6 PANS

8шт.

32

S5102703

WASHER;SPRING M12

desc: RONDELLE GROWER M12

8шт.

34

2161-9404

RUBBER;ENGINE MOUNTING

desc: CAOUTCHOUC

4шт.

35

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

18шт.

36

2114-4024A

WASHER;BUMP

desc: RONDELLE

4шт.

37

S0766666

BOLT M16X1.5X120

desc: BOULON A 6 PANS

4шт.

38

121-00035

NUT;LOCK M16X1.5

desc: ECROU

4шт.

39

2197-1381A

BRACKET

desc: SUPPORT

1шт.

40

2197-1382A

BRACKET

desc: SUPPORT

1шт.

41

S0712253

BOLT M10X1.25X30

desc: BOULON A 6 PANS

7шт.

42

S5010613

WASHER M10

desc: RONDELLE

20шт.

47

2891-1373

PLATE

desc: PLAQUE

1шт.

48

S4032633

NUT M10X1.25

desc: ECROU

1шт.

49

S0558253

BOLT M10X1.5X35

desc: BOULON A 6 PANS

2шт.
