Запчасти Doosan Daewoo PILOT PIPING(5) UPPER STRUCTURE

-

2400-1750

PILOT PIPING

SERIAL: 1-53

3

S0505053

BOLT M6X1.0X25

desc: BOULON A 6 PANS

4шт.

4

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

11

2420-9524

VALVE;REMOCON(R.H.)

desc: VANNE DE COMMANDE A DISTANCE

1шт.

13

2621-2752

PLATE

desc: PLAQUE CAOUTCHOUC

1шт.

28

2181-1951D1

TEE PF1/4(O)XPF1/4XPF1/4

desc: TE

2шт.

29

S8000111

O-RING P11

REP_PNO: 8202-009

14шт.

30

2181-1126D14

ADAPTER PF1/4(O)XPF1/4

desc: RACCORD

6шт.

44

2181-1126D89

ADAPTER PFO1/4XPF3/8

desc: RACCORD

4шт.

50

2184-1045D61

HOSE PF1/4-400L

desc: TUYAU FLEXIBLE

1шт.

53

2184-1129D20

HOSE PF1/4-550L

desc: TUYAU FLEXIBLE

1шт.

74

2184-1249D27

HOSE (S-120)3/8 1500L

SERIAL: 1-3

1шт.

74

2184-1249D16

HOSE (S-120)3/8-1350L

SERIAL: 4

1шт.

75

2184-1249D27

HOSE (S-120)3/8 1500L

SERIAL: 1-3

1шт.

75

2184-1249D16

HOSE (S-120)3/8-1350L

SERIAL: 4-8

1шт.

75

2184-1249D32

HOSE (S-120)3/8.1150L

SERIAL: 9

1шт.

84

2184-1249D14

HOSE (S-120)1/4 2850L

SERIAL: 1-3

1шт.

84

2184-1249D13

HOSE (S-120)1/4-2650L

SERIAL: 4

1шт.

91

2184-1249D7

HOSE (S-120)1/4 3100L

desc: TUYAU FLEXIBLE

1шт.

92

2184-1249D7

HOSE (S-120)1/4 3100L

desc: TUYAU FLEXIBLE

1шт.

93

2184-1249D14

HOSE (S-120)1/4 2850L

SERIAL: 1-3

1шт.

93

2184-1249D13

HOSE (S-120)1/4-2650L

SERIAL: 4

1шт.

104

2181-2604

TEE PF(O)1/4X2-PF1/4

desc: TE

1шт.

109

2420-9378A

VALVE;SHOCKLESS

desc: VANNE

2шт.

110

2181-1126D118

ADAPTER PFO1/4XPF1/4

desc: RACCORD

1шт.

114

2184-1036D167

HOSE PF1/4-650L

desc: TUYAU FLEXIBLE

1шт.
