Запчасти Doosan Daewoo MAIN PIPING(5)-TRAVEL UPPER STRUCTURE

-

2400-1749

MAIN PIPING

desc: CONDUITES DE HYDRAULIQUE PRINCIPAL

18

2180-1026D2

O-RING SAE 3/4

desc: JOINT TORIQUE

4шт.

19

S5110603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

16шт.

22

2181-4133D5

ADAPTER PFO.ORS 3/4

SERIAL: 1-143

3шт.

22

2181-2627D1

ADAPTER PFO3/4XUNF1 3/16-12

SERIAL: 144

3шт.

23

S8030121

O-RING 1 3/16-12

desc: JOINT TORIQUE

4шт.

24

S8000231

O-RING 3/4

REP_PNO: 0207-001

4шт.

27

2181-4133D13

ADAPTER PFO.ORS 3/4

SERIAL: 1-143

1шт.

27

2181-2627D3

ADAPTER PFO3/4XUNF 1 3/16-12

SERIAL: 144

1шт.

32

2181-9079

FLANGE;SPLIT SAE 3/4

desc: FLASQUE EN DEUX PARTIES

8шт.

33

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

16шт.

44

2184-1202D2

HOSE PF3/4-1550L

desc: TUYAU FLEXIBLE

1шт.

45

2184-1201D12

HOSE PF3/4-1300L

desc: TUYAU FLEXIBLE

1шт.

46

2184-1202D5

HOSE PF3/4-1300L

desc: TUYAU FLEXIBLE

1шт.

47

2184-1201D2

HOSE PF3/4-1050L

desc: TUYAU FLEXIBLE

1шт.
