Запчасти Doosan Daewoo LUBRICATION PIPING UPPER STRUCTURE

-

2400-1748

LUBRICATION PIPING

desc: JUBRIFICATION

1

2183-4798

PIPE

desc: CONDUITE

1шт.

2

2183-4420B

PIPE

desc: TUYAU

1шт.

3

2183-4419B

PIPE

SERIAL: 1-113

1шт.

4

2181-1925

ELBOW M14X1.5-PT1/8

SERIAL: 1-113

3шт.

4

2181-1925

ELBOW M14X1.5-PT1/8

SERIAL: 114

2шт.

5

S6710041

NIPPLE;GREASE

SERIAL: 1-113

4шт.

5

S6710041

NIPPLE;GREASE

SERIAL: 114

3шт.

6

2124-1027D2

CLIP;PIPE

desc: ATTACHE

2шт.

7

S0504353

BOLT M6X10

desc: BOULON A 6 PANS

2шт.

8

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

9

2181-1157A

ELBOW PT1/8

SERIAL: 1-113

1шт.

10

2181-1544

ADAPTER;PIPE M14X1.5-PT1/8

SERIAL: 1-113

3шт.

10

2181-1544

ADAPTER;PIPE M14X1.5-PT1/8

SERIAL: 114

2шт.

11

2181-1528A

ELBOW;S PT1/8

desc: COUDE

2шт.

12

2184-1045D71

HOSE PF1/4-860L

desc: TUYAU FLEXIBLE

1шт.

13

2181-1110D1

ADAPTER;S PT1/4 PF1/4

desc: RACCORD

2шт.
