Запчасти Doosan Daewoo LOW PRESSURE PIPING(1) UPPER STRUCTURE

-

2400-1747

LOW PRESSURE PIPING

desc: CONDUITES REFROIDSSEMENT

6

2193-1352B

PIPE;SUCTION

desc: CONDUITE

1шт.

7

2185-1002D104

HOSE Ґх72.6-450L

desc: TUYAU FLEXIBLE

1шт.

25

S8000241

O-RING P24

desc: JOINT TORIQUE

2шт.

25

S8000241

O-RING P24

desc: JOINT TORIQUE

1шт.

29

2180-1026D31

O-RING 2 1/2"

desc: JOINT TORIQUE

1шт.

41

S8450082

CLAMP;HOSE

desc: COLLIER

4шт.

43

S2215461

BOLT;SOCKET M12X1.75X40

desc: BOULON A 6 PANS CREUX

4шт.

48

2185-1003D36

HOSE D25-D37-190L

desc: TUYAU FLEXIBLE

1шт.

49

S8450023

CLAMP;HOSE

desc: COLLIER

4шт.

50

2140-1350

ADAPTER

desc: RACCORD

1шт.
