Запчасти Doosan Daewoo CONTROL STAND-L.H UPPER STRUCTURE

-

2197-1504

CONTROL STAND ASS'Y

desc: CONSOLE DE COMMANDE

2

2133-1997A

LEVER ASS'Y

desc: ENSEMBLE DE LEVIER

1шт.

7

2125-1078B

CASE;UPPER

desc: CARTER

1шт.

8

2125-1079

CASE;LOWER

desc: CARTER

1шт.

10

2621-2747A

COVER;SWITCH(L.H)

desc: COUVERCLE

1шт.

11

2190-2724

PLATE;NAME

desc: PLAQUE SIGNALETIQUES

1шт.

15

2195-3772

BRACKET

desc: SUPPORT

1шт.

25

S3458843

SCREW M5X0.8X14

desc: VIS

6шт.

26

S5000213

WASHER;PLAIN M5

desc: RONDELLE PLATE

10шт.

36

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

11шт.

37

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

11шт.

38

S3450623

SCREW M4X0.7X25

desc: VIS

2шт.

41

S5102103

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

42

2195-3763B

BRACKET

desc: SUPPORT

1шт.

44

2549-1134

SWITCH;MICRO

desc: COMMUTATEUR MICRO

1шт.

48

2158-1017D2

HOSE Ґх64

desc: TUYAU FLEXIBLE

1шт.

49

S8450053

CLAMP;HOSE

desc: COLLIER

2шт.

51

S0508953

BOLT M8X1.25X22

desc: BOULON A 6 PANS

10шт.

60

2197-1477A

BRACKET(L.H)

desc: SUPPORT

1шт.

64

S3458863

SCREW M5X0.8X20

desc: VIS

4шт.

66

S3458353

SCREW M3X0.5X12

desc: VIS

4шт.

67

2530-1438

HARNESS;MICRO SWITCH

desc: FAISCEAU

1шт.

70

2191-3314

PLATE

desc: PLAQUE

1шт.
