Запчасти Doosan Daewoo PROPELLING PIPING UNDER STRUCTURE

-

2400-1754

PIPING;PROPELL

desc: CONDUITES DE TRANSLATION

1

2184-1222D10

HOSE (S-135)1 3/16-12-2000L

desc: TUYAU FLEXIBLE

4шт.

2

S8030121

O-RING 1 3/16-12

desc: JOINT TORIQUE

4шт.

3

2181-4133D5

ADAPTER PFO.ORS 3/4

desc: RACCORD

4шт.

4

S8000231

O-RING P22.4

REP_PNO: 0207-001

4шт.

5

2181-9081

FLANGE;SPLIT 1"-6000PSI

desc: FLASQUE EN DEUX PARTIES

8шт.

6

2180-1026D19

O-RING SAE 1"

desc: JOINT TORIQUE

8шт.

7

S2215361

BOLT;SOCKET M12X1.75X35

desc: BOULON A 6 PANS CREUX

16шт.

8

2184-1070D16

HOSE PF1/2-1950L

desc: TUYAU FLEXIBLE

2шт.

9

2181-1126D6

ADAPTER PF1/2(O)XPF1/2

desc: RACCORD

3шт.

10

S8000181

O-RING 1/2"

REP_PNO: 8202-014

3шт.

11

2181-4124

TEE PF1/2

desc: TE

1шт.

12

2184-1046D146

HOSE PF1/4-2250L

desc: TUYAU FLEXIBLE

2шт.

13

2181-1126D14

ADAPTER PF1/4(O)XPF1/4

desc: RACCORD

3шт.

14

S8000111

O-RING P11

REP_PNO: 8202-009

3шт.

15

2181-4125

TEE PF1/4

desc: TE

1шт.

16

2160-4008A

BUSHING;RUBBER

SERIAL: 1-208

2шт.

16

2160-1322D2

BUSHING;RUBBER

SERIAL: 209

2шт.
