Запчасти Doosan Daewoo MAIN PIPING-ONE & TWO WAY OPTION PARTS

-

2400-2149

MAIN PIPING-ONE & TWO WAY

SC: D

1

2420-9633

VALVE;SWITCH

desc: VANNE

1шт.

2

2197-2680A

BRACKET

desc: SUPPORT

1шт.

3

S0515253

BOLT M12X1.75X30

desc: BOULON A 6 PANS

4шт.

4

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE M12

5шт.

5

2181-4133D6

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

6

S8030161

O-RING

desc: JOINT TORIQUE

4шт.

7

S8000291

O-RING

desc: JOINT TORIQUE

4шт.

8

S8000231

O-RING

desc: JOINT TORIQUE

3шт.

9

2181-2627D13

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

10

2181-2627D1

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

11

2184-1197D96

HOSE PF1-680L

desc: TUYAU FLEXIBLE

1шт.

12

2184-1197D13

HOSE PF1-1300L

desc: TUYAU FLEXIBLE

1шт.

13

2184-1196D87

HOSE PF1-1900L

desc: TUYAU FLEXIBLE

1шт.

14

2184-1196D87

HOSE PF1-1900L

desc: TUYAU FLEXIBLE

1шт.

15

2181-2815D1

ELBOW

desc: COUDE

1шт.

16

2181-2294D6

ELBOW

desc: COUDE

1шт.

17

S8030121

O-RING

desc: JOINT TORIQUE

3шт.

18

2140-1692

PIPE

desc: CONDUITE

1шт.

19

2124-1025D3

CLAMP;PIPE

desc: FIXATION DE TUYAU

1шт.

20

S0561053

BOLT M12X1.75X65

desc: BOULON A 6 PANS

1шт.

21

2114-1685

SHIM

desc: RONDELLE D'EPAISSEUR

2шт.

22

2181-2816D2

ELBOW

desc: COUDE

1шт.
