Запчасти Doosan Daewoo SWING REDUCTION GEAR(2) HYDRAULIC PARTS

-

2404-1058B

REDUCTION DEVICE

SERIAL: 16-53

1шт.

-

2404-1058B

REDUCTION DEVICE

SERIAL: 59

1шт.

1

2423-1460

CASING

desc: CARTER

1шт.

2

2405-1015

DRIVE SHAFT

desc: ARBRE

1шт.

3

2114-1806

SPACER

desc: BAGUE

1шт.

4

2412-1040

PLATE

desc: RONDELLE "NILOS #6304 ZAV"

1шт.

5

2109-9033

BEARING;ROLLER

desc: ROULEMENT A BILLES

1шт.

6

2180-1254

SEAL;OIL

desc: JOINT D'HUILE

1шт.

7

2109-1050

BEARING;ROLLER

desc: ROULEMENT A BILLES

1шт.

8

2412-1047

PLATE;THRUST

desc: PLAQUE

1шт.

9

2230-1032

CARRIER #2

desc: SUPPORT

1шт.

10

S0121061

BOLT;HEXAGON

desc: BOULONE A 6 PANS

1шт.

11

2104-1012

GEAR;RING

desc: PIGNON

1шт.

12

2123-1901

PIN;KNOCK

desc: GOUPILLE

4шт.

13

2182-1306

PIPE

desc: TUYAU

4шт.

14

2114-1554A

WASHER;THRUST

desc: RONDELLE DE BUTEE

8шт.

15

2101-1029B

GEAR;PLANET #2

desc: PIGNON

4шт.

16

2123-1038C

PIN #2

desc: BROCHE

4шт.

17

2123-1633D1

PIN;SPRING

desc: GOUPILLE ELASTIQUE

7шт.

18

2101-1028A

GEAR;SUN #2

desc: PIGNON

1шт.

19

2230-1016

CARRIER #1

desc: SUPPORT

1шт.

20

2412-9001

PLATE;SIDE #1

desc: PLAQUE LATERALE

3шт.

21

2123-2161

PIN #1

desc: BROCHE

3шт.

22

2216-1012

CAGE;NEEDLE

desc: CAGE

3шт.

23

2412-9002

PLATE;SIDE #2

desc: PLAQUE LATERALE

3шт.

24

2101-1027B

GEAR;PLANET #1

desc: PIGNON

3шт.

25

S6500500

RING;STOP

desc: ANNEAU DE BLOCAGE

3шт.

26

2412-9004B

PLATE;SIDE #3

desc: PLAQUE LATERALE

1шт.

27

2101-1026A

GEAR;SUN #1

desc: PIGNON

1шт.

28

S6500450

RING;STOP

desc: ANNEAU DE BLOCAGE

1шт.

29

2181-1116D4

PLUG PT1/2

desc: BOUCHON

1шт.

30

2181-1116D2

PLUG PT1/4

desc: BOUCHON

2шт.

31

S2223671

BOLT;SOCKET M16X2.0X170

desc: BOULON A 6 PANS CREUX

12шт.

32

2182-1510

PIPE;LEVEL GAUGE

desc: TUYAU

1шт.

33

2505-1009

BAR;LEVEL

desc: BARRE

1шт.

34

S5231090

WASHER;DOUBLE TAB

desc: RONDELLE

1шт.

35

2159-1147

PLATE;COVER

desc: COUVERCLE

1шт.

36

S0112061

BOLT;HEXAGON

desc: BOULON A 6 PANS

8шт.
