Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01304-0003

CASE;TIMING GEAR

SERIAL: 970328

1шт.

1

65.01304-0003C

CASE;TIMING GEAR

SERIAL: 970329

1шт.

2

06.22022-3119

PIN

desc: BROCHE

1шт.

3

06.01913-3120

BOLT;HEX. M8X45

desc: BOULON A 6 PANS

2шт.

5

06.01913-3113

BOLT ASS'Y M8X20

desc: BOULON A 6 PANS

4шт.

7

65.01304-5022

COVER;TIMING GEAR CASE

SERIAL: 970616

1шт.

7

65.01304-5074

COVER;TIMING GEAR CASE

SERIAL: 970617

1шт.

8

06.22022-3111

PIN

desc: BROCHE

1шт.

10

06.01913-3115

BOLT ASS'Y M8X25

desc: BOULON A 6 PANS

7шт.

12

06.01913-3122

BOLT;HEX. M8X55

desc: BOULON A 6 PANS

5шт.

14

65.01307-0002

COVER;TIMING CHECK HOLE

SERIAL: 981205

2шт.

14

65.01307-0002B

COVER;TIMING CHECK HOLE

SERIAL: 981206

2шт.

15

06.01283-6911

BOLT;HEX. M6X16

SERIAL: 981205

4шт.

15

06.01913-2911

BOLT ASS'Y M6X16

SERIAL: 981206

4шт.

16

06.16731-2105

WASHER;SPRING

SERIAL: 981205

4шт.

22

65.01510-0001

SEAL;OIL(FRONT)

desc: JOINT D'HUILE

1шт.

23

65.01903-0002

COVER;GASKET(T.G.C)

SERIAL: 960903

2шт.

23

65.01903-0002C

COVER;GASKET(T.G.C)

SERIAL: 960904

2шт.

24

65.01903-0003

COVER;GASKET(T.G.C)

SERIAL: 960903

1шт.

24

65.01903B0003

COVER;GASKET(T.G.C)

SERIAL: 960904

1шт.

25

65.01903-0004

CASE;GASKET(T.G.C)

SERIAL: 960903

1шт.

25

65.01903B0004

CASE;GASKET(T.G.C)

SERIAL: 960904

1шт.
