Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

-

65.03101-6049

CYLINDER HEAD ASS'Y

desc: ENSEMBLE CULASSE

1шт.

1

65.03101-1043

HEAD;CYLINDER

SC: D

1шт.

2

65.03201-1013

GUIDE;VALVE

SC: D

12шт.

3

65.03203-1020

SEAT;EXHAUST VALVE

SC: D

6шт.

4

65.03203-1019

SEAT;INLET VALVE

SC: D

6шт.

5

65.90302-0015

PLUG;CORE(NEAR FACE)

desc: . BOUCHON

1шт.

6

65.90302-0016

PLUG;CORE(EXHAUST MAIN)

desc: . BOUCHON

3шт.

7

65.90302-0019B

PLUG;CORE

desc: . COUPELLE

11шт.

8

06.15090-2313

PLUG;CORE

desc: . BOUCHON

3шт.

9

06.15090-2305

PLUG;CORE

desc: . BOUCHON

6шт.

10

65.90302-0011

PLUG;DRILLED PASS

desc: . BOUCHON

6шт.

11

65.90302-0017

PLUG;WATER JET CORE

desc: BOUCHON

6шт.

13

06.06125-8711

BOLT;STUD M8X45

desc: GOUJON

12шт.

14

06.06225-0706

BOLT;STUD M8X25

desc: GOUJON

3шт.

15

06.06125-8717

BOLT;STUD M8X75

desc: GOUJON

7шт.

16

06.06125-8709

STUD BOLT M8X35

desc: GOUJON

2шт.

16-1

06.06125-8711

BOLT;STUD M8X45

desc: . GOUJON

2шт.

16-2

06.06125-8723

BOLT;STUD

desc: GOUJON

1шт.

17

65.91710-0004

RING;STOPPER

desc: ANNEAU DE BLOCAGE

2шт.

18

65.90020-0006

BOLT;CYLINDER HEAD

SERIAL: 970723

20шт.

18

65.90020-0294

BOLT;CYLINDER HEAD

SERIAL: 970724

20шт.

19

65.90020-0160

BOLT;CYLINDER HEAD

SERIAL: 970723

6шт.

19

65.90020-0295

BOLT;CYLINDER HEAD

SERIAL: 970724

6шт.

20

65.03401-6035

CYLINDER HEAD COVER ASS'Y

SERIAL: 960722

1шт.

20

REP_PNO: 65.90701-0202

20

REP_PNO: 65.90725-0023

20

REP_PNO: 65.90501-0028

20

65.03401-6043

CYLINDER HEAD COVER ASS'Y

SERIAL: 001022

1шт.

20

65.03401-6057

CYLINDER HEAD COVER ASS'Y

SERIAL: 001023

1шт.

22

65.90501-0160

NUT;CYLINDER HEAD COVER

SERIAL: 001022

4шт.

22

65.90501-0028

NUT;CYLINDER HEAD COVER

SERIAL: 001023

4шт.

23

65.90701-0018

WASHER;PLATE

SERIAL: 001022

4шт.

23

65.90701-0202

WASHER;PLATE

SERIAL: 001023

4шт.

24

65.90725-0002

PACKING

SERIAL: 001022

4шт.

24

65.03905-0023A

PACKING

SERIAL: 001023

4шт.

25

65.03901-0032

GASKET;CYLINDER HEAD

SERIAL: 971160

1шт.

25

65.03901-0055

GASKET;CYLINDER HEAD

SERIAL: 971008

1шт.

26

65.03905-0002

PACKING;CYLINDER HEAD COVER

SERIAL: 990728

1шт.

26

65.03905-0002B

PACKING;CYLINDER HEAD COVER

SERIAL: 990729

1шт.

27

65.01810-5160

CAP;OIL FILLER

desc: BOUCHON

1шт.

28

65.04902-0011

SEAL;VALVE STEM

SERIAL: 971001

12шт.

28

65.04902-0011A

SEAL;VALVE STEM

SERIAL: 971002

12шт.

29

65.03435-0001

COVER;CYLINDER HEAD COVER

SERIAL: 960722

1шт.

29

65.01801-5097

BREATHER PIPE ASS'Y

SERIAL: 960723

1шт.

30

65.03903-0001

PACKING;FOR COVER

desc: RONDELLE ETANCHE

1шт.

31

06.67020-0102

CLAMP

desc: COLLIER

1шт.

32

65.96301-0226

HOSE;RUBBER

SERIAL: 991113

1шт.

32

REP_PNO: 65.97401-0144

1шт.

32

65.96301-0322

HOSE;RUBBER

SERIAL: 991114

1шт.

33

06.04190-2805

SCREW

SERIAL: 960722

6шт.

33

06.04190-8808

BOLT M5X16

SERIAL: 960723

6шт.

34

06.16731-2104

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

35

06.15010-0308

WASHER

SERIAL: 960723

6шт.

36

65.01801-0011

BREATHER CASE

SERIAL: 960723

1шт.

37

65.96501-0032B

O-RING

SERIAL: 960723

1шт.

38

65.97401-0144

CLIP;HOSE FOR OIL COOLER

SERIAL: 991114

2шт.

39

65.96001-0008

CAP;RUBBER

SERIAL: 960723

1шт.

40

06.67020-0102

CLAMP

SERIAL: 960723

1шт.
