Запчасти Doosan Daewoo PILOT PIPING-ROTATING & TILTING OPTION PARTS

-

400-00658

PILOT PIPING-ROTATION & TILTING

SC: D

-2шт.

1

420-00160

VALVE;PEDAL

desc: VANNE

1шт.

2

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

2шт.

3

S5110603

WASHER

desc: RONDELLE ELASTIQUE

4шт.

4

2197-1817

BRACKET;PEDAL(R.H)

desc: SUPPORT

1шт.

5

S2211866

BOLT;SOCKET M10X1.5X20

desc: BOULON A 6 PANS CREUX

2шт.

6

2161-2257

RUBBER;PEDAL

desc: CAOUTCHOUC

1шт.

7

2181-1126D14

ADAPTER PFO1/4-PF1/4

desc: ADAPTEUR

2шт.

8

S8000111

O-RING 1/4

desc: JOINT TORIQUE

2шт.

9

2181-1951D19

TEE PFO1/2-PF1/2-PF1/4

desc: TE

2шт.

10

2184-1046D44

HOSE PF1/4-460L

desc: TUYAU FLEXIBLE

1шт.

11

2184-1046D68

HOSE PF1/4-600L

desc: TUYAU FLEXIBLE

1шт.
