Запчасти Doosan Daewoo AIRCONDITIONER(1) BODY PARTS

-

920-00103

COOLER & HEATER ASS'Y

SC: D

-2шт.

1

543-00049

PANEL;AIRCON CONTROL

desc: PANNEAU

1шт.

2

S3450583

SCREW M4X0.7X12

desc: VIS

4шт.

3

S5000113

WASHER;PLAIN M4

desc: RONDELLE PLATE

4шт.

4

2208-6013B

COMPRESSOR

desc: COMPRESSEUR

1шт.

5

S0557153

BOLT M8X1.25X90

desc: BOULON A 6 PANS

4шт.

6

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

7

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

4шт.

8

2197-1798B

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

9

S0712153

BOLT M10X1.25X28

desc: BOULON A 6 PANS

1шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

11

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

12

2107-6006

PULLEY ASS'Y;IDLE 4PK

desc: POULIE

1шт.

13

S0759853

BOLT M10X1.25X115

desc: BOULON A 6 PANS

2шт.

14

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

15

2106-1019D10

BELT 4PK 990L AIR CON

desc: COURROIE

1шт.

16

2185-1705

HOSE;DISCHARGE 2585L

desc: TUYAU FLEXIBLE

1шт.

16A

2180-6089

O-RING(COND)

desc: . JOINT TORIQUE

1шт.

16B

2180-6088

O-RING(COMP)

desc: . JOINT TORIQUE

1шт.

16C

1.161-00018

CAP;CHECK PORT(H)

desc: . CHAPEAU

1шт.

17

2185-1702A

HOSE;SUCTION 2795L

desc: TUYAU FLEXIBLE

1шт.

17A

2180-6086

O-RING(COMP)

desc: . JOINT TORIQUE

1шт.

17B

2180-6087

O-RING(EVA)

desc: . JOINT TORIQUE

1шт.

17C

1.161-00019

CAP;CHECK PORT(L)

desc: . CHAPEAU

1шт.

18

2520-6004

CONDENSER ASS'Y

desc: CONDENSATEUR

1шт.

18A

2520-6005

CONDENSER CORE ASS'Y

desc: . NOYAU

1шт.

18B

2538-6018

MOTOR;CONDENSER

desc: . MOTEUR

1шт.

18C

2520-6006

NET;CONDENSER MOTOR

desc: . FILET

1шт.

19

S0512053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

6шт.

20

S5102603

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

21

S5010613

WASHER;PLAIN M8

desc: RONDELLE PLATE

6шт.

22

2185-1697D2

HOSE;LIQUID(1) 530L

desc: TUYAU FLEXIBLE

1шт.

22A

2180-6090

O-RING

desc: . JOINT TORIQUE

2шт.

23

2185-1698D1

HOSE;LIQUID(2) 2650L

desc: TUYAU FLEXIBLE

1шт.

23A

2180-6090

O-RING

desc: . JOINT TORIQUE

2шт.

24

2204-6039A

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

25

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

26

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

27

920-00020B

UNIT;AIRCON

desc: UNITE D'AIRCON

1шт.

28

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

6шт.

29

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

30

2114-1058D29

WASHER

desc: RONDELLE

6шт.

38

124-00208D3

CLIP D20/M8

desc: CLIP

1шт.

39

124-00208D7

CLIP D44/M8

desc: CLIP

1шт.

40

124-00209D1

CLIP 2-D20/M8

desc: CLIP

2шт.

42

120-00276

BOLT M8X1.25X12

desc: BOULON A 6 PANS

3шт.
