Запчасти Doosan Daewoo ACOUSTIC FOAM BODY PARTS

-

161-00490

ACOUSTIC FOAM ASS'Y

SC: D

-2шт.

1

621-02380

COVER

desc: COUVERCLE

1шт.

2

621-02381

COVER

desc: COUVERCLE

1шт.

3

2161-2160B

FOAM;POLYURETHANE

desc: EPONGE

1шт.

4

2161-2161B

FOAM;POLYURETHANE

desc: EPONGE

1шт.

5

2161-2162B

FOAM;POLYURETHANE

desc: EPONGE

1шт.

6

2161-2163B

FOAM;POLYURETHANE

desc: EPONGE

1шт.

7

2161-2164B

FOAM;POLYURETHANE

desc: EPONGE

1шт.

8

2161-2274A

FOAM;POLYURETHANE

desc: EPONGE

1шт.

9

2161-2275A

FOAM;POLYURETHANE

desc: EPONGE

1шт.

10

2161-2276

FOAM;POLYURETHANE

desc: EPONGE

1шт.

11

2161-2277A

FOAM;POLYURETHANE

desc: EPONGE

2шт.

12

621-02382

COVER

SERIAL: 1001-1911

1шт.

12

621-02382A

COVER

SERIAL: 1912-2195

1шт.

12

621-02382B

COVER

SERIAL: 2196

1шт.

13

2621-3652A

COVER

desc: COUVERCLE

1шт.

14

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

2шт.

15

2114-1058D10

WASHER

desc: RONDELLE

2шт.

16

2161-2165A

FOAM;POLYURETHANE

desc: EPONGE

1шт.

17

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

9шт.

18

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

9шт.

19

S5010513

WASHER

desc: RONDELLE

9шт.

20

161-00554

FOAM;POLYURETHANE

SERIAL: 1031

1шт.
