Запчасти Doosan Daewoo TRAVEL PIPING TRACK PARTS

-

400-00142A

TRAVEL PIPING

SC: D

-2шт.

1

DS2017038

HOSE PF3/4-2000L

desc: TUYAU FLEXIBLE

4шт.

2

S8030121

O-RING

desc: JOINT TORIQUE

4шт.

3

2181-2627D1

ADAPTER PF3/4-UNF1 3/16

desc: ADAPTEUR

4шт.

4

S8000231

O-RING

desc: JOINT TORIQUE

4шт.

5

2181-9081

FLANGE;SPLIT

desc: BRIDE

8шт.

6

2180-1026D19

O-RING SAE1

desc: JOINT TORIQUE

8шт.

7

S2215366

BOLT;SOCKET M12X1.75X35

desc: BOULON DE PLOT

16шт.

8

2184-1026D435

HOSE PF1/2-1900L

desc: TUYAU FLEXIBLE

2шт.

9

2181-1126D6

ADAPTER PFO1/2-PF1/2

desc: ADAPTEUR

2шт.

10

S8000181

O-RING

desc: JOINT TORIQUE

3шт.

11

2181-2281D10

TEE 3-PF1/2

desc: TE

1шт.

12

2184-1046D135

HOSE PF1/4-2500L

desc: TUYAU FLEXIBLE

2шт.

13

2181-1126D14

ADAPTER PFO1/4-PF1/4

desc: ADAPTEUR

1шт.

14

S8000111

O-RING

desc: JOINT TORIQUE

3шт.

15

2181-4125

TEE 3-PF1/4

desc: TE

1шт.

16

2160-1322D1

RUBBER;BUSHING

desc: GARNISSAGE CAOUTCHOUC

2шт.

17

2181-1702D56

ELBOW

desc: COUDE

2шт.
