Запчасти Doosan Daewoo ENGINE CONTROL ASSY BODY PARTS

-

133-00218

ENGINE CONTROL ASS'Y

SC: D

-2шт.

1

2197-1777A

BRACKET

desc: SUPPORT

1шт.

2

S0711853

BOLT M10X1.25X20

desc: BOULON A 6 PANS

2шт.

3

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

4

S0504553

BOLT M6X1.0X14

desc: BOULON A 6 PANS

3шт.

5

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

3шт.

6

2150-1122

HOOK;CABLE

desc: CROCHET

1шт.

7

133-00029A

LEVER

desc: LEVIER

1шт.

8

S4012533

NUT M8X1.25

desc: ECROU

3шт.

9

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

9шт.

10

195-00183B

BRACKET

desc: SUPPORT

1шт.

11

2138-9006B

JOINT;BALL

desc: ENSEMBLE DE JOINT

1шт.

12

S0509353

BOLT M8X1.25X35

desc: BOULON A 6 PANS

2шт.

13

S4012233

NUT M5X0.8

desc: ECROU

1шт.

14

S5102203

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

15

523-00004

ACTUATOR;ENGINE CONTROL

desc: MOTEUR

1шт.

16

2523-9016

MOTOR;ENGINE STOP

desc: MOTEUR

1шт.

17

159-00124

PLATE

desc: PLAQUE

1шт.

18

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

6шт.

19

S5010513

WASHER M8

desc: RONDELLE M8

2шт.

20

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

2шт.

21

S5010613

WASHER M8

desc: RONDELLE

2шт.

22

195-01848A

BRACKET

desc: SUPPORT

1шт.

23

S0508453

BOLT M8X1.25X12

desc: BOULON A 6 PANS

3шт.

24

2124-1509D10

CLIP

desc: ATTACHE

2шт.

25

2139-6055D16

CABLE;CONTROL

desc: CABLE

1шт.

26

2124-1509D1

CLIP

desc: ATTACHE

1шт.

27

S0515053

BOLT M12X1.75X25

desc: BOULON A 6 PANS

2шт.

28

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

2шт.

29

S5010713

WASHER M12

desc: RONDELLE

2шт.

30

195-02694

BRACKET

desc: SUPPORT

1шт.
