Запчасти Doosan Daewoo ELECTRIC BOX ASSY-ELECTRIC PARTS BODY PARTS

-

500-00260A

ELECTRIC BOX ASS'Y

desc: EQUIPMENT ELECTRIQUE

1шт.

2

543-00104

CONTROLLER;e-EPOS

desc: COMMANDE EPOS

1шт.

3

S4012633

NUT M10X1.5

desc: ECROU

4шт.

4

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

5

S5010613

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

6

543-00074

CONTROLLER;THROTTLE

desc: COMMANDE EPOS

1шт.

7

S4012333

NUT M6X1.0

desc: ECROU

4шт.

8

S5102303

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

9

S5010313

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

10

2190-3231D5

PLATE;NAME (PRM SETTING)

desc: PLAQUE D'IDENTIFICATION

1шт.

11

2543-9015

CONTROLLER;STARTER

desc: COMMANDE DEMARREUR

1шт.

12

S3450943

SCREW M6X1.0X10

desc: VIS

2шт.

13

S5102303

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

14

2537-9008

TIMER;WIPER

desc: INTERRUPTEUR

1шт.

15

S3450943

SCREW M6X1.0X10

desc: VIS

2шт.

16

S5102303

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

17

2531-1003

CONVERTER;DC-DC (1)

desc: CONVERTEUR

1шт.

18

S3450953

SCREW M6X1.0X12

desc: VIS

2шт.

19

S5102303

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

20

2531-1003

CONVERTER;DC-DC (2)

desc: CONVERTEUR

1шт.

21

S3450953

SCREW M6X1.0X12

desc: VIS

2шт.

22

S5102303

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

23

2516-1116

BUZZER;PILOT

desc: VIBREUR ARRIERE

1шт.

24

S3450943

SCREW M6X1.0X10

desc: VIS

2шт.

25

S5102303

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

26

2544-9033

RELAY;HAED LAMP 24V 20/30A

desc: RELAIS

1шт.

27

2544-9033

RELAY;WORKING LAMP 24V 20/30A

desc: RELAIS

1шт.

28

2544-9033

RELAY;ENGINE STOP 24V 20/30A

desc: RELAIS

1шт.

29

2544-9033

RELAY;HORN 24V 20/30A

desc: RELAIS

1шт.

30

2544-9033

RELAY;COMPRESSOR 24V 20/30A

desc: RELAIS

1шт.

31

2544-9033

RELAY;CONDENSER FAN 24V 20/30A

desc: RELAIS

1шт.

32

2544-9033

RELAY;STEREO 24V 20/30A

desc: RELAIS

1шт.

33

2544-9033

RELAY;AFTER HEAT 24V 20/30A

desc: RELAIS

1шт.

34

2190-2037D19

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

35

2190-2037D20

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

36

2190-2037D56

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

37

530-00207A

HARNESS;ELECTRIC BOX

desc: FAISCEAU

1шт.

38

530-00208B

HARNESS;CABIN

desc: FAISCEAU

1шт.

39

S3450823

SCREW M5X0.8X10

desc: VIS

5шт.

40

S5100203

WASHER;SPRING

desc: RONDELLE ELASTIQUE

5шт.

41

124-00208D3

CLIP D20/M8

desc: ATTACHE

2шт.

42

124-00208D5

CLIP D32/M8

desc: ATTACHE

1шт.

43

124-00208D6

CLIP D38/M8

desc: ATTACHE

2шт.

44

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

2шт.

45

S4012533

NUT M8X1.25

desc: ECROU

4шт.

46

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.
