Запчасти Doosan Daewoo NAME PLATE-PICTORIAL OTHER PARTS

-

9190-1044

NAME PLATE ASS'Y

SC: D

-2шт.

1

2190-3385D1

PLATE;NAME (DAEWOO)

desc: PLAQUE;NOM DE LA FIRME

2шт.

2

2190-3385D2

PLATE;NAME (DAEWOO)

desc: PLAQUE;NOM DE LA FIRME

1шт.

3

190-00090

KEEP OFF SWING AREA

desc: RESTER HORS ZONE DE GIRATON

2шт.

4

2190-3406

PLATE;NAME-SIDE:"130LC-V"

SERIAL: 1-50153

2шт.

4

9190-1042

PLATE;NAME-SIDE:"150LC-V"

SERIAL: 50154-50270

2шт.

4

190-00851

PLATE;NAME-SIDE:"SOLAR"

SERIAL: 50271

1шт.

5

2190-3332

PLATE;NAME- SIDE"SOLAR"

SERIAL: 1-50270

2шт.

5

190-01125

PLATE;NAME-SIDE:"150LC-V"

SERIAL: 50271

1шт.

6

190-00146

MAINTENANCE INTERVALS

SERIAL: 1-50143

1шт.

6

190-00146A

MAINTENANCE INTERVALS

SERIAL: 50144-50220

1шт.

6

190-00146B

MAINTENANCE INTERVALS

SERIAL: 50221

1шт.

7

190-00100

PLATE;NAME-BATTERY

desc: PLAQUE D'IDENTIFICATION

1шт.

8

2122-1002D2

RIVET

desc: RIVET

4шт.

9

190-00092

ADVICE;MANUAL

desc: CONSEIL;LIRE MANUEL

1шт.

10

2190-3297

CONTROL LEVER;ISO PICTURE

desc: LEVIER COMMANDE;DESSIN ISO

1шт.

11

2190-2314D3

TAPE;ANTI-SKID

desc: BANDE ANTI-DERAPANTE

9шт.

12

2190-3309

LOCK CONTROL LEVER;ISO PICTURE

desc: VERROUILLAGE COMMANDES ISO

1шт.

13

190-00095

KEEP HANDS AWAY

desc: GARDER MAIN LOIN VENTILATEUR

1шт.

14

190-00101

EMERGENCY;USE HAMMER

desc: SI URGENCE;UTILISER LE MARTEAU

1шт.

15

2190-3244D1

FUSE LOCATION;ON FUSE BOX

desc: EMPLACEMENT DES FUSIBLES

1шт.

16

190-00099

ACCUMULATOR;WARNING

desc: ACCUMULATEUR;NE PAS PERCER

1шт.

17

2190-3239

WORLD 21

SERIAL: 1-50270

1шт.

17

190-00980

PLATE;NAME-SIDE:"SOLAR"

SERIAL: 50271

1шт.

18

2116-9003

PLATE;CUSHION

desc: CAOUTCHOUC

1шт.

19

2190-2524

EXTINGUISHER LOCATION

desc: EMPLACEMENT EXTINCTEUR

1шт.

20

190-00096

DANGER ELECTRIC LINE

desc: ATTENTION AUX LIGNES ELECTRIQUES

1шт.

21

190-00093

SLIDE WINDOW:LOCK WHEN RAISED

desc: BAIE VITREE:VERROU SI LEVEE

1шт.

22

190-00098

MAINTENANCE;DO NOT OPERATE

desc: MAINTENANCE;NE PAS UTILISER

1шт.

23

190-00122

TRACK ADJUSTER HANDLING

desc: AJUSTEUR TENSION CHENILLE

2шт.

24

2190-1892D2

PLATE;NAME

desc: PLAQUE NOM DE LA FIRME

1шт.

25

190-00315

WINDOW;LOCK WHEN RAISED

desc: FENETRE:VERROU SI LEVEE

1шт.

26

190-00102

AVOID CRANE WORK

desc: NE PAS UTILISER COMME GRUE

1шт.

28

2190-2476

CHAIN;ISO DRAWING

desc: CHAINE;DESSIN ISO

4шт.

29

2190-2477

HOOK;ISO DRAWING

desc: CROCHET;DESSIN ISO

4шт.

30

91XX-1006

MADE IN BELGIUM

desc: FAIT EN BELGIQUE

1шт.

31

190-00097

AVOID SPURTING

desc: EVITER ECLABOUSSURES D'HUILE

2шт.

32

2190-3270D20

PLATE;"103LWA"(SOUND POWER)

SERIAL: 1-50220

1шт.

33

2190-3271D8

PLATE;"76LA"(SOUND PRESS.)

SERIAL: 1-50220

1шт.

34

2190-3558D1

PLATE;NAME(EUROPE-E/G EMISSION)

SERIAL: 1-50250

1шт.

34

190-00509D13

PLATE;NAME(EUROPE-E/G EMISSION)

SERIAL: 50251

1шт.

35

2124-1622D1

CLIP;BAND

desc: ATTACHE

1шт.

36

2190-3528

RED/WHITE STRIPS REFLECTIVE

SERIAL: 1-50230

3шт.

37

2190-3530

RED/WHITE STRIPS REFLECTIVE

SERIAL: 1-50230

1шт.

37

190-00647

RED/WHITE STRIPS REFLECTIVE

SERIAL: 50231

1шт.

38

190-00091

KEEP OF WORK AREA

SERIAL: 1-50220

2шт.

38

190-00652

KEEP OF WORK AREA

SERIAL: 50221

2шт.

39

190-00094

MACHINE AT REST

desc: POSITION PARKING

1шт.

40

190-00730D15

PLATE;"104LWA"(GUARANT.)

SERIAL: 50221-50270

1шт.

40

190-01059D15

PLATE;"104LWA"(GUARANT.)

SERIAL: 50271

1шт.

41

190-00557

PLATE;NAME-FAN;WARNING

SERIAL: 50221

1шт.

42

190-01126

PLATE;NAME-SIDE:"150LC-V"

SERIAL: 50271

1шт.
