Запчасти Doosan Daewoo BUCKET-0.44§©-HD OPTION PARTS

-

2704-1631A

BUCKET SUB ASS'Y-0.44m©ш

desc: GODET

1шт.

1

2704-1602A

BUCKET-0.44m©ш(OPT.)

desc: GODET

1шт.

1-1

-

BUCKET;WELD

SC: D

1шт.

1-1A

2713-1222A

ADAPTER;TOOTH

desc: .. DENT D' ADAPTEUR

5шт.

1-2

2713-1221A

POINT;TOOTH

desc: . DENT

5шт.

1-3

2705-1022

PIN;LOCKING

desc: . GOUPILLE DE BLOCAGE

5шт.

1-4

2114-1859

WASHER;LOCKING

desc: . RONDELLE

5шт.

2

2713-1228

CUTTER;SIDE(R)

SERIAL: 1-50190

1шт.

2

2713-1228A

CUTTER;SIDE(R)

SERIAL: 50191

1шт.

3

2713-1229

CUTTER;SIDE(L)

SERIAL: 1-50190

1шт.

3

2713-1229A

CUTTER;SIDE(L)

SERIAL: 50191

1шт.

4

S0570061

BOLT

SERIAL: 1-50190

8шт.

4

S0574561

BOLT

SERIAL: 50191

8шт.

5

S4013133

NUT

SERIAL: 1-50190

8шт.

5

S4013333

NUT

SERIAL: 50191

8шт.

6

2114-9012

WASHER;HARDEN

SERIAL: 1-50190

8шт.

6

2114-1831

WASHER;HARDEN

SERIAL: 50191

8шт.
