/ / / / / INTAKE & EXHAUST MANIFOLD
Запчасти Doosan Daewoo INTAKE & EXHAUST MANIFOLD ENGINE PARTS
301
306
307
318
319
329
317
315
302
304
332
333
303
320
334
323
318
313
321
325
101
314
322
330
103
309
323
310
312
101A
105
106
305
104
311
328
327
308
107
102
103
101
201
219
212
216
215
214
101D
101D
101B
101C
101
65.08101-6058
MANIFOLD;EXHAUST
SERIAL: 980916
1шт.
101A
65.08101-0038
MANIFOLD;EXHAUST(L.H.)
SERIAL: 980916
1шт.
101B
65.08101-0198
MANIFOLD;EXHAUST(M)
SERIAL: 980916
1шт.
101C
65.08101-0164
MANIFOLD;EXHAUST(R.H.)
SERIAL: 980916
1шт.
101D
65.96507-0013
RING;SEAL
SERIAL: 980916
6шт.
101
65.08101-0535
MANIFOLD;EXHAUST
SERIAL: 020821
1шт.
101
65.08101-0199
MANIFOLD;EXHAUST
SERIAL: 020822
1шт.
102
06.06175-8206
BOLT;STUD M10X1.25X25
SERIAL: 001012
3шт.
103
06.06175-8208
BOLT;STUD M10X1.25X30
SERIAL: 001012
1шт.
103
06.06175-8208
BOLT;STUD M10X1.25X30
SERIAL: 001013
4шт.
104
06.16731-2107
WASHER;SPRING
desc: RONDELLE ELASTIQUE
12шт.
105
06.15010-2311
WASHER
desc: RONDELLE
12шт.
106
06.11063-8214
NUT
desc: ECROU
12шт.
107
65.08901-0001
GASKET;MANIFOLD EXHAUST
SERIAL: 020821
3шт.
107
65.08901-0028
GASKET;MANIFOLD EXHAUST
SERIAL: 020822
3шт.
201
65.08201-0011D
MANIFOLD;INTAKE
desc: COLLECTEUR
1шт.
212
06.01923-3115
BOLT ASS'Y
desc: BOULON A 6 PANS
8шт.
214
06.11063-8214
NUT
desc: ECROU
3шт.
215
06.16731-2107
WASHER;SPRING
desc: RONDELLE ELASTIQUE
3шт.
216
06.15010-2311
WASHER
desc: RONDELLE
3шт.
219
65.08902-0004
GASKET;INTAKE MANIFOLD
SERIAL: 970218
1шт.
219
65.08902A0004
GASKET;INTAKE MANIFOLD
SERIAL: 970219
1шт.
301
65.09100-7040
TURBO CHARGER ASS'Y
SERIAL: 020821
1шт.
301
65.09100-7040A
TURBO CHARGER ASS'Y
SERIAL: 020822
1шт.
302
06.06225-0708
BOLT;STUD M8X30
desc: GOUJON
4шт.
303
06.11063-8214
NUT
desc: ECROU
4шт.
304
06.16731-2107
WASHER;SPRING
desc: RONDELLE ELASTIQUE
4шт.
305
65.97480-0135
HOLDER
desc: POSSESSEUR
1шт.
306
06.11024-9202
NUT
desc: ECROU
4шт.
307
06.16731-2108
WASHER;SPRING
desc: RONDELLE
4шт.
308
65.98155-0011
UNION;HOLLOW
desc: GRAISSEUR
1шт.
309
65.98130-0200
ADAPTER
desc: RACCORD ADAPTATEUR
1шт.
310
06.56190-0709
RING;SEAL
desc: BAGUE D'ETANCHEITE
1шт.
311
65.05701-5342
OIL PIPE ASS'Y
desc: CONDUITE
1шт.
312
06.01913-3110
BOLT ASS'Y
desc: BOULON A 6 PANS
1шт.
313
06.78144-2403
SCREW;HOLLOW
desc: VIS CREUSE
1шт.
314
06.56190-0704
RING;SEAL
desc: BAGUE D'ETANCHEITE A16X20
2шт.
315
65.05701-5343
PIPE;OIL
desc: CONDUITE
1шт.
317
65.96301-0279
HOSE;RUBBER
desc: TUYAU FLEXIBLE
1шт.
318
06.67020-0109
CLAMP;HOSE
desc: COLLIER NWS32
2шт.
319
65.96601-0045A
GASKET;T/C OIL RETURN
desc: JOINT
1шт.
320
06.01913-3115
BOLT ASS'Y M8X25
desc: BOULON A 6 PANS
2шт.
321
65.96301-0280A
HOSE;RUBBER
desc: TUYAU FLEXIBLE
1шт.
322
06.67020-0106
CLAMP;HOSE
desc: COLLIER
2шт.
323
65.09901-0019
GASKET
SERIAL: 020821
1шт.
323
65.09901-0018A
GASKET
SERIAL: 020822
1шт.
325
65.09901-0020
GASKET
desc: JOINT
1шт.
327
06.56180-0714
RING;SEAL
desc: BAGUE D'ETANCHEITE
2шт.
328
06.12172-9314
NUT;CAP
desc: CHAPEAU DE ECROU
1шт.
329
65.08202-0243
PIPE;INLET
desc: CHAPEAU DE ECROU
1шт.
330
65.96601A0007
GASKET
desc: JOINT
1шт.
331
06.06225-0704
BOLT;STUD M8X20
desc: GOUJON
3шт.
332
06.11063-8214
NUT;HEX M8
desc: CHAPEAU DE ECROU
3шт.
333
06.16731-2107
WASHER;SPRING
desc: RONDELLE
3шт.
334
06.15010-2311
WASHER
desc: CHAPEAU DE ECROU
3шт.
335
65.96301-0279
HOSE;RUBBER
desc: CHAPEAU DE ECROU
1шт.
336
06.67020-0109
HOSE;CLAMP
desc: CHAPEAU DE ECROU
2шт.
