Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

218
206
228
207
208
223
220
219
201
212
224
213
210
214
227
226
225
219
117
112
102
111
108
118
123
128
119
129
105
124
106
130
131
120
122
121
120
132
101
116
104
109
109
127
107
125
133
134
110

Артикул

Название

Примечание

Количество

101

65.03101-6049

CYLINDER HEAD ASS'Y

SERIAL: 020919

1шт.

101

65.03101-6071A

CYLINDER HEAD ASS'Y

SERIAL: 020920

1шт.

102

65.03101-1043

HEAD;CYLINDER

SERIAL: 020919

1шт.

102

65.03101-1043C

HEAD;CYLINDER

SERIAL: 020920

1шт.

104

65.03201-1013

GUIDE;VALVE

SC: D

12шт.

105

65.03203-1020

SEAT;EXHAUST VALVE

SERIAL: 020919

6шт.

105

65.03203-1054

SEAT;EXHAUST VALVE

SERIAL: 020920

6шт.

106

65.03203-1019

SEAT;INLET VALVE

SERIAL: 020919

6шт.

106

65.03203-1053

SEAT;INLET VALVE

SERIAL: 020920

6шт.

107

65.90302-0015

PLUG;CORE(NEAR FACE)

desc: . BOUCHON

1шт.

108

65.90302-0016

PLUG;CORE(EXHAUST MAIN)

SERIAL: 020919

3шт.

108

65.90302-0030

PLUG;CORE(EXHAUST MAIN)

SERIAL: 020920

6шт.

109

65.90302-0019B

PLUG;CORE

desc: . COUPELLE

11шт.

110

06.15090-2313

PLUG;CORE

SERIAL: 020919

3шт.

110

65.90302-0045

PLUG;CORE

SERIAL: 020920

3шт.

111

06.15090-2305

PLUG;CORE

SERIAL: 020919

6шт.

111

65.90302-0027

PLUG;CORE

SERIAL: 020920

6шт.

112

65.90302-0011

PLUG;DRILLED PASS

desc: . BOUCHON

6шт.

116

06.06225-0706

BOLT;STUD

desc: GOUJON

3шт.

117

06.06125-8717

BOLT;STUD

desc: GOUJON

10шт.

118

06.06125-8709

BOLT;STUD

desc: GOUJON

1шт.

119

65.91710-0004

RING;STOPPER

desc: BAGUE

2шт.

120

65.90020-0006

BOLT;CYLINDER HEAD

SERIAL: 970723

19шт.

120

65.90020-0294

BOLT;CYLINDER HEAD

SERIAL: 970724

19шт.

120

65.90020-0294

BOLT;CYLINDER HEAD

SERIAL: 000706

20шт.

121

65.90020-0007

BOLT;CYLINDER HEAD

SERIAL: 970723

6шт.

121

65.90020-0295

BOLT;CYLINDER HEAD

SERIAL: 970724

6шт.

122

65.90020-0027

BOLT;CYLINDER HEAD

SERIAL: 970723

1шт.

122

65.90020-0296

BOLT;CYLINDER HEAD

SERIAL: 970724

1шт.

122

65.90020-0296

BOLT;CYLINDER HEAD

SERIAL: 000705

1шт.

123

06.06125-8723

BOLT;STUD

desc: GOUJON

1шт.

124

65.19202-5005

HOOK;LIFTING

desc: CROCHET

1шт.

125

65.03901-0055

GASKET;CYLINDER HEAD

desc: JOINT

1шт.

127

65.26810-0007

CONNECTOR

desc: RACCORD

1шт.

128

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

129

06.01733-4409

BOLT;HEX M14X1.5X25

desc: BOULON A 6 PANS

1шт.

130

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

131

06.01733-4208

BOLT M10X1.25X22

desc: BOULON A 6 PANS

1шт.

132

65.26803-7014B

PLUG;GLOW

desc: PRISE DE LUEUR

6шт.

133

65.19202-0005

HOOK;LIFTING

desc: CROCHET

1шт.

134

06.01943-3213

BOLT ASS'Y M10X1.25X20

desc: BOULON A 6 PANS

2шт.

201

65.03401-6043A

CYLINDER HEAD COVER ASS'Y

SERIAL: 001129

1шт.

201

REP_PNO: 65.03905-0023

-1шт.

201

REP_PNO: 65.90701-0202

-1шт.

201

REP_PNO: 65.90501-0028

-1шт.

201

65.03401-6057

CYLINDER HEAD COVER ASS'Y

SERIAL: 030529

1шт.

201

65.03401-6064

CYLINDER HEAD COVER ASS'Y

SERIAL: 030530

1шт.

206

65.90501-0007

NUT;CYLINDER HEAD COVER

SERIAL: 991029

4шт.

206

65.90501-0028

NUT;CYLINDER HEAD COVER

SERIAL: 991030

4шт.

207

65.90701-0018

WASHER;PLATE

SERIAL: 991029

4шт.

207

65.90701-0202

WASHER;PLATE

SERIAL: 991030

4шт.

208

65.03905-0002

GASKET;CYL. HEAD COVER

SERIAL: 991029

4шт.

208

65.03905-0023

GASKET;CYL. HEAD COVER

SERIAL: 020416

4шт.

208

65.03905-0023A

GASKET;CYL. HEAD COVER

SERIAL: 020417

4шт.

210

65.01801-0011

CASE;BREATHER

desc: BOITE

1шт.

212

06.04190-8808

BOLT M5X16

desc: BOULON A 6 PANS

6шт.

213

06.16731-2104

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

214

06.15010-0308

WASHER;PLAIN

desc: RONDELLE

6шт.

218

65.96301-0226

HOSE;RUBBER

SERIAL: 991112

1шт.

218

65.96301-0322

HOSE;RUBBER

SERIAL: 021008

1шт.

218

65.96301-0354

HOSE;RUBBER

SERIAL: 021009

1шт.

219

06.67020-0102

CLAMP

SERIAL: 001129

2шт.

219

06.67020-0102

CLAMP

SERIAL: 021008

1шт.

219

06.67020-0105

CLAMP

SERIAL: 021009

1шт.

220

65.01810-5005

CAP;OIL FILLER

SERIAL: 951212

1шт.

220

65.01810-5007

CAP;OIL FILLER

SERIAL: 951213

1шт.

223

65.01801-5097

BREATHER PIPE ASS'Y

SERIAL: 021008

1шт.

223

REP_PNO: 65.01801-0354

-1шт.

223

REP_PNO: 65.01801-0179

-1шт.

223

REP_PNO: 65.01801-0105

-1шт.

223

65.01801-5035

BREATHER PIPE ASS'Y

SERIAL: 021009

1шт.

224

65.96501-0032B

O-RING

desc: JOINT TORIQUE

1шт.

225

65.96001-0008

CAP;RUBBER

SERIAL: 001129

1шт.

226

65.03905-0002

GASKET;CYLINDER HEAD COVER

SERIAL: 991029

1шт.

226

65.03905-0002B

GASKET;CYLINDER HEAD COVER

SERIAL: 991030

1шт.

227

65.03903-0001

PACKING;COVER

desc: RONDELLE D'ETANCHEITE

1шт.

228

65.97401-0141

CLIP;WATER HOSE

SERIAL: 000921

1шт.

228

65.97401-0144

CLIP;WATER HOSE

SERIAL: 021008

2шт.

228

65.97401-0179

CLIP;WATER HOSE

SERIAL: 021009

2шт.

Выбрано товаров: 79
