Запчасти Doosan Daewoo ENGINE MOUNTING BODY PARTS

-

2201-1070A

ENGINE ASS'Y

SC: D

-2шт.

1

2201-9057

ENGINE-DB58T

SERIAL: 1-50250

1шт.

1

201-00165

ENGINE-DB58T

SERIAL: 50251

1шт.

5

2114-1816A

WASHER;HARDEN

SERIAL: 50241

4шт.

11

S5102603

WASHER;SPRING M10

desc: RONDELLE GROWER

8шт.

29

2197-1399A

BRACKET

desc: SUPPORT

1шт.

30

2197-1400A

BRACKET

desc: SUPPORT

1шт.

31

S0786253

BOLT M12X1.5X30

desc: BOULON A 6 PANS

8шт.

32

S5102703

WASHER;SPRING M12

desc: RONDELLE GROWER

8шт.

34

2161-9404

RUBBER;ENGINE MOUNTING

desc: SILENT BLOC

4шт.

35

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

16шт.

36

2114-1811

WASHER;REBOUND

desc: RONDELLE ELASTIQUE

4шт.

37

S0766666

BOLT M16X1.5X120

desc: BOULON A 6 PANS

4шт.

38

S4032933

NUT M16X1.5

SERIAL: 1-50143

4шт.

38

121-00035

NUT;LOCK M16X1.5

SERIAL: 50144

4шт.

39

2197-1381A

BRACKET

desc: SUPPORT

1шт.

40

2197-1382A

BRACKET

desc: SUPPORT

1шт.

41

S0712253

BOLT M10X1.25X30

desc: BOULON A 6 PANS

7шт.

42

S5010613

WASHER M10

desc: RONDELLE

18шт.

48

S4032633

NUT M10X1.25

desc: ECROU

1шт.

49

S0558253

BOLT M10X1.5X35

desc: BOULON A 6 PANS

2шт.
