Запчасти Doosan Daewoo ELECTRIC PARTS(4)-BATTERY BODY PARTS

-

2500-1179

ELECTRIC PARTS(4)-BATTERY

SC: D

-2шт.

1

2506-1104

BATTERY 100AH

SERIAL: 1-50143

2шт.

1

506-00002

BATTERY 100AH

SERIAL: 50144

2шт.

2

2514-1005

HOLDER;BATTERY

desc: SAISIR

2шт.

3

2120-1419

BOLT;STUD M10X1.5X210

desc: BOULON A 6 PANS

4шт.

4

S4012633

NUT M10X1.5

desc: ECROU M10X1.5

4шт.

5

2124-1441

CLIP

desc: ATTACHE

4шт.

6

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

7

S4540603

NUT;WING M10X1.5

desc: ECROU

4шт.

8

2544-9024

RELAY;BATTERY

desc: RELAIS BATTERIE

1шт.

9

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

2шт.

10

S5102503

WASHER;SPRING M8

desc: RONDELLE GROWER

2шт.

11

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

12

2527-9004

BREAKER;CIRCUIT 60A

desc: COUPE-CIRCUIT

1шт.

13

2120-1354

SCREW

desc: VIS

2шт.

14

2527-1023A

FUSIBLE LINK 0.5SQ 27A

desc: FUSIBLE

2шт.
