Запчасти Doosan Daewoo SWING REDUCTION GEAR SWING DEVICE

-

404-00062

SWING REDUCTION GEAR

desc: REDEUTEUR D'ORIENTATION

1шт.

1

402-00017

CASING

desc: CARTER

1шт.

2

405-00006

SHAFT;DRIVE

desc: ARBRE

1шт.

3

104-00019

GEAR;RING

desc: PIGNON

1шт.

4

404-00063

GEAR;PLANET NO.2

desc: PIGNON

4шт.

5

404-00064

GEAR;SUN NO.2

desc: PIGNON

1шт.

6

404-00065

GEAR;PLANET NO.1

desc: PIGNON

3шт.

7

404-00066

GEAR;SUN NO.1

desc: PIGNON

1шт.

8

230-00017

CARRIER NO.2

desc: SUPPORT

1шт.

9

230-00018

CARRIER NO.1

desc: SUPPORT

1шт.

10

123-00094

PIN ASS'Y NO.2

desc: GOUPILLE

4шт.

11

123-00095

PIN ASS'Y NO.1

desc: GOUPILLE

3шт.

12

2114-1594

WASHER;THUST(B)

desc: RONDELLE

13шт.

13

2114-1592

WASHER;THUST(A)

desc: RONDELLE

2шт.

14

119-00003

BAR;LEVEL

desc: CONDUITE

1шт.

15

182-00009

PIPE;LEVEL GAUGE

desc: CONDUITE

1шт.

16

123-00096

PIN;KNOCK

desc: GOUPILLE

2шт.

17

2109-1041

BEARING;ROLLER

desc: PALIER

1шт.

18

2109-1042

BEARING;ROLLER

desc: PALIER

1шт.

19

S2216873

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

10шт.

20

180-00179

SEAL;OIL

desc: BAGUE DE HUILE

1шт.

21

2181-1116D4

PLUG(B)

desc: BOUCHON

1шт.

22

2181-1116D2

PLUG(A)

desc: BOUCHON

2шт.

23

S5740890

PIN;SPRING

desc: GOUPILLE

3шт.

24

S6500300

RING;RETAINER

desc: JONC D'ARRET

4шт.

25

S6500650

RING;RETAINER

desc: JONC D'ARRET

1шт.

26

115-00037

RING;NILOS

desc: BAGUE

1шт.

27

S5740900

PIN;SPRING

desc: GOUPILLE

4шт.

28

191-00167

PLATE;SUPPORT

desc: PLAQUE

2шт.

29

S3453116

BOLT;SCREW

desc: BOULON

6шт.
