Запчасти Doosan Daewoo WATER PUMP & COOLING FAN ENGINE PARTS

101

65.06500-6402B

WATER PUMP ASS'Y

desc: POMPE DE EAU

1шт.

102

65.06501-0217A

HOUSING

SC: D

1шт.

103

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

104

65.93410-0027

BEARING

desc: . PALIER

1шт.

105

06.29020-0132

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

106

65.06504-0033

HUB;V-BELT PULLEY

desc: . MOYEU

1шт.

107

65.06506-0085A

IMPELLER

desc: . TURBINE

1шт.

108

65.06512-0016

COVER

desc: . COUVERCLE

1шт.

109

65.06901-0035A

GASKET

desc: . JOINT

1шт.

110

06.04200-9009

SCREW;CROSS M8X20

desc: . VIS

3шт.

112

06.01493-4215

BOLT M10X1.25X80

desc: BOULON

1шт.

113

06.01493-4212

BOLT M10X1.25X65

desc: BOULON

2шт.

114

06.01943-3218

BOLT ASS'Y M10X1.25X35

desc: ENSEMBLE DE BOULON

1шт.

115

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

116

65.06606-0039

PULLEY;FAN

desc: POLLEY

1шт.

117

65.06901B0002

GASKET

desc: JOINT

1шт.

118

65.96301-0363

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

120

06.67020-0104

CLAMP;HOSE

desc: COLLIER DE LA CONDUITE

4шт.

124

65.96301-0364

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

201

65.06601-0012A

FAN;COOLING

desc: VENTILATEUR

1шт.

202

65.06611-0099A

FLANGE;FAN

desc: BRIDE

1шт.

203

65.06611-0089A

FLANGE;FAN

desc: BRIDE

1шт.

204

06.01013-9124

BOLT M8X95

desc: BOULON

4шт.

205

06.01923-3119

BOLT ASS'Y M8X40

desc: ENSEMBLE DE BOULON

4шт.

206

06.15010-2311

WASHER

desc: RONDELLE

4шт.

207

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

208

06.11063-8214

NUT;HEX M8

desc: ECROU 6 PANS

4шт.

209

65.96801-0124A

BELT

desc: COURROIE

1шт.
