Запчасти Doosan Daewoo ELECTRIC PARTS-BATTERY BODY PARTS

-

9500-1009

ELECTRIC ASS'Y

SC: D

-2шт.

1

506-00003

BATTERY

desc: BATTERIE

2шт.

2

2197-1119

BRACKET;BATTERY

desc: SUPPORT

1шт.

3

2120-1036D12

BOLT

desc: BOULON

2шт.

4

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

5

S5010613

WASHER;PLAIN

desc: RONDELLE

8шт.

6

2544-9024

RELAY;BATTERY

desc: RELAIS

1шт.

7

S0509053

BOLT

desc: BOULON

2шт.

8

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

9

S5010513

WASHER;PLAIN

desc: RONDELLE

2шт.

10

2527-9004

BREAKER;CIRCUIT

desc: SUPPORT

1шт.

11

2120-1354

SCREW

desc: VIS

2шт.

12

2527-1023A

LINK;FUSIBLE

desc: ARTICULATION

1шт.

20

2544-1022

RELAY;STARTER

desc: RELAIS

1шт.

21

2197-1660

BRACKET;HOUSING

desc: SUPPORT

1шт.

22

S0504653

BOLT

desc: BOULON

3шт.

23

S5010303

WASHER;PLAIN

desc: RONDELLE

3шт.

24

S5102313

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

25

S4012333

NUT

desc: ECROU

3шт.
