Запчасти Doosan Daewoo CABIN WITHOUT ROOF & DOOR(1) BODY PARTS

-

9622-6028

CABIN WITHOUT DOORS AND ROOF

SC: D

-2шт.

1

SZ95.501.692

WINDOW;FRONT

desc: VITRE

1шт.

2

SZ10.298.00

KNOB;FRONT WINDOW

desc: BOUTON

18шт.

3

F6X30.CL8-8.N

BOLT

desc: BOULON

9шт.

4

M6.CL8.B

WASHER

desc: RONDELLE

9шт.

5

NYLSTOP.M6

NUT

desc: ECROU

9шт.

6

SZ08.095.00

ARM;WIPER

desc: BALANCIER

1шт.

7

SZ08.020.00

BLADE;WIPER

desc: LAME

1шт.

8

SZ95.825.227

SUPPORT;LIGHT

desc: SUPPORT

1шт.

9

HM6X20.CL8-8.B

BOLT

desc: BOULON

4шт.

10

DE6.CL8.B

WASHER

desc: RONDELLE

4шт.

11

M6.CL8.B

WASHER

desc: RONDELLE

4шт.

12

SZ95.725.924

SUPPORT;LIGHT

desc: SUPPORT

1шт.

13

TCC5.5X16.CL8-8.N

BOLT

desc: BOULON

2шт.

14

SZ95.800.556

SUPPORT;RADIO

desc: SUPPORT

1шт.

15

SZ09.182.00

SPEAKER

desc: HAUT-PARLEUR

2шт.

16

SZ06.083.00.3300

JOINT;ADHESIVE

desc: JOINT

1шт.

17

SZ95.704.754

REST;FOOT

desc: REPOS DE PIED

1шт.

18

SZ95.704.754

FOOT REST ASS'Y

desc: REPOS DE PIED

1шт.

19

SZ95.050.282

FLOOR ASSEMBLY

desc: ENSEMBLE DE PLANCHER

1шт.

20

SZ95.050.284

SLIP;NON

desc: NON GLISSADE

1шт.

21

SZ95.050.280

ASSEMBLY

desc: ENSEMBLE

1шт.

22

SZ95.050.279

ASSEMBLY

desc: ENSEMBLE

1шт.
