Запчасти Doosan Daewoo DOZER PIPING OPTION PARTS

-

400-00303

DOZER PIPING

SC: D

-2шт.

1

140-00259A

PIPE

desc: TUYAU

1шт.

2

140-00260A

PIPE

desc: TUYAU

1шт.

3

2184-1197D174

HOSE 400L

desc: TUYAU FLEXIBLE

1шт.

4

2184-1197D69

HOSE 600L

desc: TUYAU FLEXIBLE

1шт.

5

2184-1198D82

HOSE 870L

desc: TUYAU FLEXIBLE

2шт.

7

2181-4133D46

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

8

2181-4133D3

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

9

S8000181

O-RING

desc: JOINT TORIQUE

6шт.

10

S8030081

O-RING

desc: JOINT TORIQUE

12шт.

11

2124-1340D9

CLAMP;PIPE

desc: FIXATION DE TUYAU

1шт.

12

S0560553

BOLT M12X1.75X40

desc: BOULON A 6 PANS

3шт.

13

S5102703

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

3шт.

14

S5010713

WASHER;PLAIN

desc: RONDELLE

3шт.

15

2124-1340D3

CLAMP;PIPE

desc: FIXATION DE TUYAU

2шт.

16

2184-1198D80

HOSE 870L

desc: TUYAU FLEXIBLE

2шт.

18

2181-4133D3

ADAPTER UNF1 3/16-PFO1/2

desc: RACCORD ADAPTATEUR

2шт.
