Запчасти Doosan Daewoo ARM PIPING(3.0M)-ROTATION & TILTING OPTION PARTS

-

400-00867

ARM PIPING(3.0m)-ROTATION & TILTING

SC: D

-2шт.

1

701-00413A

ARM;WELDMENT

desc: BALANCIER

1шт.

2

DS2013356

HOSE ORS1/2-1250L

desc: TUYAU FLEXIBLE

2шт.

3

140-01122

PIPE;ARM

desc: TUYAU

2шт.

4

140-01115A

PIPE;TILTING

desc: TUYAU

2шт.

5

193-00625A

PIPE;ROTATING

desc: TUYAU

2шт.

6

420-00277

VALVE;SWITCH

desc: VANNE

2шт.

7

2181-1702D2

ELBOW PFO1/2-PF1/2

desc: COUDE

2шт.

8

111-00031D1

ADAPTER;UNION PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

6шт.

9

2181-1126D6

ADAPTER PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

4шт.

10

2181-2820D3

PLUG

desc: BOUCHON

4шт.

11

S8000181

O-RING

desc: JONT TORIQUE

14шт.

12

124-00204A

CLAMP

desc: ATTACHE

10шт.

13

S2212066

BOLT;SOCKET M10X1.5X25

desc: BOULON A 6 PANS CREUX

20шт.

14

161-00313

RUBBER

desc: CAOUTCHOUC

20шт.

15

S8030081

O-RING

desc: JONT TORIQUE

2шт.

16

2181-4133D3

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.
