Запчасти Doosan Daewoo SEAT & ELECTRIC BOX BODY PARTS

-

195-01710G

SEAT & ELECTRIC COVER

SERIAL: 1001-1189

-2шт.

-

195-01710H

SEAT & ELECTRIC COVER

SERIAL: 1190-1376

-2шт.

-

195-01710J

SEAT & ELECTRIC COVER

SERIAL: 1377

-2шт.

3

901-00024E

PLATE;SEAT

desc: PLAQUE

1шт.

4

194-00024

RAIL;SEAT

desc: CHEMIN DE FER

1шт.

15

2114-1898D3

WASHER M6

desc: RONDELLE

6шт.

16

2114-1898D4

WASHER;PLAIN M5

desc: RONDELLE PLATE

2шт.

22

2120-2166D5

BOLT M8X1.25X20

desc: BOULON A 6 PANS

4шт.

23

2114-1898D2

WASHER M8

desc: RONDELLE

8шт.

26

2121-1311D2

NUT M8X1.25

desc: ECROU

8шт.

37

2120-2166D46

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

38

621-01824

COVER;ELEC. BOX(FRONT)

desc: COUVERCLE

1шт.

39

2120-2166D7

SCREW M6X1.0X14

desc: VIS

6шт.

41

621-01825

COVER;ELEC. BOX(L.H)

desc: COUVERCLE

1шт.

42

2114-2031D4

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

43

S0514853

BOLT M12X1.75X20

desc: BOULON A 6 PANS

4шт.

44

2114-1058D46

WASHER

desc: RONDELLE

4шт.
