Запчасти Doosan Daewoo ENGINE MOUNTING BODY PARTS

-

601-00014A

ENGINE ASS'Y

SERIAL: 1001-1458

-2шт.

-

601-00014B

ENGINE ASS'Y

SERIAL: 1459

-2шт.

1

201-00183

ENGINE-DB58TI

desc: MOTEUR

1шт.

11

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

29

195-02583

BRACKET

SERIAL: 1001-1123

1шт.

29

195-02583A

BRACKET

SERIAL: 1124

1шт.

30

195-02584A

BRACKET

SERIAL: 1001-1123

1шт.

30

195-02584B

BRACKET

SERIAL: 1124

1шт.

31

S0786253

BOLT M12X1.5X30

desc: BOULON A 6 PANS

8шт.

32

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

8шт.

34

2161-9066

RUBBER;ENGINE MOUNTING

SERIAL: 1001-1693

4шт.

34

161-00548

RUBBER;ENGINE MOUNTING

SERIAL: 1694

4шт.

36

2114-1929

WASHER

desc: RONDELLE ELASTIQUE

4шт.

37

S0771466

BOLT M20X1.5X130

SERIAL: 1001-1209

4шт.

37

S0771266

BOLT M20X1.5X120

SERIAL: 1210

4шт.

38

121-00066

NUT;LOCK M20X1.5

desc: ECROU

4шт.

39

195-02581

BRACKET

desc: SUPPORT

1шт.

40

195-02582A

BRACKET

desc: SUPPORT

1шт.

41

S0712253

BOLT M10X1.25X30

desc: BOULON A 6 PANS

7шт.

42

S5010613

WASHER M10

desc: RONDELLE

2шт.

45

S4032633

NUT M10X1.25

desc: ECROU

1шт.

46

S0558253

BOLT M10X1.5X35

desc: BOULON A 6 PANS

2шт.

51

4161-9067

RUBBER;ENGINE MOUNTING

SERIAL: 1001-1758

4шт.

51

161-00550

RUBBER;ENGINE MOUNTING

SERIAL: 1759

4шт.

52

2114-9012A

WASHER;HARD

desc: RONDELLE ELASTIQUE

8шт.
