Запчасти Doosan Daewoo PILOT PIPING-PRO-MONO OPTION PARTS

-

9400-1135A

PEDAL INSTALL

SC: D

-2шт.

2

9420-1010

PEDAL ASS'Y(L.H)

SC: D

1шт.

2-1

420-00347

VALVE;PEDAL

desc: . VANNE

1шт.

2-2

195-01736

BRACKET;PEDAL(L.H)

desc: . SUPPORT

1шт.

2-3

S2212266

BOLT;SOCKET M10X1.5X30

desc: . BOULON A 6 PANS CREUX

2шт.

2-4

S5110601

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

4шт.

2-5

S5010613

WASHER;PLAIN

desc: . RONDELLE PLAQUE

2шт.

2-6

161-00386

RUBBER;PEDAL

desc: . CAOUTCHOUC

1шт.

2-7

195-01940

LOCK;PEDAL(R.H)

desc: . LOCK

1шт.

2-8

2120-2166D5

BOLT M8X1.25X20

desc: . BOULON A 6 PANS

2шт.

2-9

2114-1898D14

WASHER

desc: . RONDELLE

2шт.

2-10

S2211866

BOLT;SOCKET M10X1.5X20

desc: . BOULON A 6 PANS CREUX

2шт.

2-11

160-00045

BUSHING;RUBBER

desc: . GARNISSAGE

1шт.

3

2184-1046D198

HOSE PF1/4-400L

desc: TUYAU FLEXIBLE

1шт.

4

2184-1046D68

HOSE PF1/4-600L

desc: TUYAU FLEXIBLE

1шт.

5

2181-1951D19

TEE PFO1/2-PF1/2-PF1/4

desc: TE

1шт.

6

2181-1126D14

ADAPTER PFO1/4-PF1/4

desc: ADAPTATEUR

2шт.

7

S8000111

O-RING

desc: JOINT TORIQUE

2шт.

9

2181-4125

TEE

desc: TE

1шт.

10

2184-1046D61

HOSE PF1/4-1750L

desc: TUYAU FLEXIBLE

1шт.

12

S8000181

O-RING

desc: JOINT TORIQUE

1шт.
